DAS ACTION 515 Speaker Pasif 15 Inch 2 Way 8 Ohm 1400 Watt
DAS ACTION 515 Speaker Pasif 15 Inch 2 Way 8 Ohm 1400 Watt - Image 2

DAS ACTION 515 Speaker Pasif 15 Inch 2 Way 8 Ohm 1400 Watt

Passive, 350 W, 15”, 2 way full-range, 90×60 rotatable horn, black

Chat Penjual
Categories: , Tags: , , , Brand:
Das
Pengiriman Cepat

100% ORIGINAL

Pengiriman Cepat

HARGA Kompetitif

Pengiriman Cepat

GARANSI Resmi

Pengiriman Cepat

AFTERSALES Service

Description

ACTION-515 is a passive system designed to deliver a highly versatile solution, from fixed installations to the popular portable PA application. Its rotatable horn with 90º x 60º dispersion means the enclosure can be used horizontally in a fixed installation, as a stage monitor or even as front fill.
As part of our company culture, all our systems are developed under a single philosophy: to deliver the highest possible quality in terms of both materials and overall system design. In the ACTION-500 series we use the same birch plywood as our touring systems for a tight, natural warm sound found nowhere else on the market.
For long-term optimal performance of the ACTION-500 passive versions, the system can only be a complete sound system when rounded out with our amplifiers and processors with stored presets and limiters.

Fitur

  • Passive two-way system
  • Birch plywood enclosure
  • Durable ISO-flex paint
  • Recommended processor: DSP-226
  • Recommended amplifier: PA series

Spesifikasi

Performance
Frequency Range (-10 dB) 47 Hz – 20 kHz
Horizontal Coverage (-6 dB) 90º
Vertical Coverage 60º
Nominal Impedance 8 ohms
RMS Power Handling 350 W
Peak Power Handling 1400 W
On-axis Sensitivity 1W/1 m 96 dB SPL
Maximum Peak SPL at 1 m 131 dB

Connectors
Audio Input Connector 1 x speakON NL4
Audio Output Connector 1 x speakON NL4
Enclosure
Enclosure Construction Birch Plywood
Enclosure Geometry Trapezoidal
Rigging M10 Rigging Points
Finish ISO-flex Paint
Color Black
Depth 385 mm (15,2 in)
Dimensions ( H x W x D ) 720 x 445 x 385 mm
28,3 x 17,5 x 15,2 in
Net Weight 22,0 kg ( 50,2 lb )
Components
LF Driver 15MI
HF Driver M-34
Horn/Waveguide BC-916
Shipping
Carton Dimensions ( H x W x D ) 785 x 430 x 505 mm
30,9 x 16,9 x 19,9 in
Shipping Weight 24,5 kg ( 54,0 lb )
