Description
MP100V2 is a tube microphone amplifier. its creative electronic circuit combines tube and FET functional to add the tonal versatility and catches detail sound quality. Via TRANS & TUBE knob to adjust the ratio between trans and tube which makes MP100V2 suitable for various mics. The high quality 12AX7B tube amplifies sound in a premium way which makes the output sound more clear and natural. Various knobs, alum and steel material make MP100V2 fashionable and durable.
Fitur
- Tube mic amplifier
- Its shell adopts dust-free spraying processing
- Provides extra shielding against stray magnetic and RF
- Features tube/fet and MTR button
- Adopts 12AX7B tube DI circuit design to premium performance
- Front panel mic gain knob increases gain and makes sound full and smooth
- Features 48V phantom power
Spesifikasi
| * Type: | tube microphone preamp |
| * Input: | XLR and 1/4’’ jack |
| * Output: | XLR |
| * Tube complement: | 12a x 7 |
| * Pad: | -15dB |
| * Max power consumption: | 160mA @120V AC, 20W |
| * Power requirements: | 100-240V AC |
| * Mic input impedance: | 2K ohm |
| * Line input impedance: | 10K ohm |
| * Hi-Z input impedance: | 2.2M ohm |
| * Internal output impedance: | 600 ohm |
| * Gain range: | 70dBu |
| * Mic gain range: | 10-60dBu |
| * Line gain range: | -10-40dBu |
| * Hi-Z gain range: | -10-40dBu |
| * Mic frequency response: | 20hz-20khz |
| * Line frequency response: | 20hz-20khz |
| * Hi-Z frequency response: | 20hz-20khz |
| * Min THD + noise @+4dBu: | 0.1% tube 0.005% |
