TOA A-5006 Digital Mixer Amplifier 60 Watt
Digital Mixer Amplifier 60 Watt
100% ORIGINAL
HARGA Kompetitif
GARANSI Resmi
AFTERSALES Service
Description
The A-5006 is a half-rack 1-unit size 60 W desktop mixer power amplifier. Inputs 1 and 2 can be set for either MIC or LINE sound sources, and its output is compatible with both high-impedance (100 V and 70 V lines) and low-impedance (4 Ω) speaker connections. Functions can be set with a PC using the dedicated setting software. The A-5006 is ideal for use as a power amplifier in small commercial facilities and conference rooms. With the use of an optional rack mounting bracket, it can be mounted in an EIA Standard equipment rack (1 unit size).
- 60 W or 120 W
- 2 x mic/line inputs with mute function
- 5-band Parametric Equalizer for each input and output (DSP)
- Remote Master Volume Control
- Mute (Mic 1 priority: Manual mute)
- Compressor for both input 1 and 2
Application examples for this product:
- Restaurants
- Bars
- Hotels
- Retail stores
- Auditoriums
| Power Source | 100-240 V AC, 50/60 Hz |
|---|---|
| Rated Output | 60 W |
| Power/Current Consumption | 106 W (rated output), 20 W (based on cULus standards) Max. 2 A |
| Frequency Response | 50 Hz – 20 kHz (1/8 rated output) |
| Distortion | 1 % or less (1 kHz, rated output) |
| Input | INPUT 1, 2: MIC -60 dB(*1) LINE -20 dB(*1) MIC/LINE selectable 2.2 kΩ, electronically-balanced, removable terminal block (5 pins) INPUT 3, 4: LINE -20 dB(*1), 10 kΩ, unbalanced, RCA pin jack |
| Output | SPEAKER: 4 Ω, 70 V (83 Ω), 100 V (170 Ω), removable terminal block (5 pins) |
| Signal to Noise Ratio | MIC 1, 2: 50 dB or more LINE 1 – 4: 70 dB or more (A-weighted) |
| Function | Parametric equalizer: 5 points settable on each input and output 20 Hz – 20 kHz ±15 dB Q: 0.267 – 69.249 Compressor: ON/OFF settable on Inputs 1 and 2 (OFF by default) Threshold, Ratio, Attack time, Release time, and Gain are settable independently on each input. |
| Control | Mute control, Remote master volume control, Power ON/OFF switch, Ground lift |
| LED Indicator | Power indicator, Signal indicator, Peak indicator, Protect indicator |
| Network I/F | 100BASE-TX |
| Operating Temperature | 0 ℃ to +40 ℃ (32 ゜F to 104 ゜F) |
| Operating Humidity | 35 % to 80 %RH (no condensation) |
| Finish | Panel: PS resin, black Case: Surface-treated steel plate, black, paint |
| Dimensions | 210 (W) × 52.5 (H) × 375 (D) mm (8.27 × 2.07″ × 14.76″)” |
| Weight | 3.6 kg (7.94 lb) |
| Accessory | CD (setting software) …1, Large type removable terminal plug (5 pins) …1, Small type removable terminal plug (5 pins) …2, Plain washer (*2) …6, Bracket mounting screw (M3 x 10) (*2) …6, Power supply cord (2 m (6.56 ft)) …1 |
| Option | Half width blank panel: MB-15B-BK (for rack mounting one A-5006 unit) (*2) Rack joint bracket: MB-15B-J (for rack mounting two A-5006 units) (*2) Rack runner: YA-706 |
