Shure BLX14R/B98 Wireless Instrument Microphone System

Description

The Shure BLX14R/B98 brings brass, woodwind, and percussion players a cost-effective wireless instrument microphone system with quality sound, simple setup, intuitive operation, and dependable performance right out of the box. It includes the rugged BLX4R single-channel receiver with LCD display, adjustable output level, and removable antennas for rackmounting the unit—ideal for sound-reinforcement applications in small venues, wedding halls, and houses of worship.

The BLX14R/B98 also includes a bodypack transmitter and a WB98H/C cardioid gooseneck mic with an integrated clip ready to attach to your instrument. The receiver features one-touch QuickScan frequency selection to quickly search 123 available frequencies and locate a clean RF channel in case of interference. The system provides up to 14 hours of continuous use with two AA batteries, at a range up to 300′. Up to 12 mic channels can operate simultaneously in each frequency band.

ALSO IN THE BOX

• 1 – 53A8611 RACK MOUNT BRACKET
• 1 – 53A8612 LONG RACK MOUNT BRACKET
• 1 – 53B8443 LINK BRACKET
• 1 – 90AZ8100 HARDWARE KIT
• 1 – 90F4046 Swivel Adapter
• 1 – 31B1856 Thread Adapter
• 2 – 95A8699 ANTENNA/BNC,1/4 WAVE
• 2 – 95A8994 ADAPTER,BULKHEAD,BNC
• 1 – 95B2313 BAG VINYL, ZIPPERED
• 2 – 95K2035 CABLE,BNC,22 in.
• 1 – Power supply

BLX1 Bodypack Transmitter:

• TQG connection for use with Shure lavalier, headset, earset and instrument microphones and guitar cables
• Toggle on/off switch
• 26dB adjustable gain control
• Lightweight, rugged construction

BLX4R Single Channel Half-rack Receiver:

• One-touch QuickScan frequency selection quickly locates the best open frequency (in case of interference)
• Up to 12 compatible systems per frequency band (region-dependent)
• XLR and ¼” output connectors
• Adjustable audio output level
• Removable antennas for quick antenna setup
• LCD Display with detailed RF and audio metering
• Rack mount kit included
