Marani DPA880T Matrix Mixer Audio 8 Channel 8×8 (8 Input, 8 Output)
8 In – 8 Out Digital Matrix System
100% ORIGINAL
HARGA Kompetitif
GARANSI Resmi
AFTERSALES Service
Description
The DPA880T is a high performance 8 input x 8 output digital Matrix mixer. Designed for maximum versatility, it provides all the processing and control necessary for fixed installation use. Particularly suitable for conference system applications and other applications with multiple microphones and loudspeakers. It includes 8 independently switchable Line/Mic inputs with Phantom power supply, 8 Line outputs, managed by a powerful MARANI® DSP Engine, in addition to high performance 24 Bit AD/DA converters. The DPA880T supports a full matrix mixing mode where inputs may be routed/mixed in any ratio to any output. Each Mic/Line input channel provides Low/High-Pass 1st order filters, 3-band Parametric EQ, Noise Gate function and Gain control. In addition Mic inputs include a Feedback Eliminator function, based on a powerful “Pitch Shifting” algorithm, particularly suitable for voice applications. Each output offers up to 5-band of parametric equalization, in addition to the crossover filters which themselves provide slopes from 6dB/Octave upto 24dB/Octave. Each output path also features RMS compressor, Peak Limiter and configurable Delay. For remote configuration and control the DPA880T can be connected via Ethernet, USB or RS485 by using the control remote PC software. In addition, it can be managed by an Apple iPad® device, using the dedicated DPA880xT software setting all parameters For complex systems, 4 digital Input and 4 digital output ports are provided for GPIO Integration allowing connection to various devices. Furthermore the DPA880T can be connected via RS485 to the optional CP4 Wall Panel control that allows selection of 4 assigned presets and master volume control.
Fitur
| Outstanding Performance | Excellent sonic performance with 24bit converters coupled with 48kHz sample rate 8 Mic/Line inputs, 8 outputs with full matrix mixing |
| Top-grade DSP Engine | 3 band parametric equalization and Low/High pass filters per input channel 5 band parametric equalization per output channel Each band can be switched to Peaking, Low/High Shelving with variable Q response Crossover filters with slopes from 6dB/Octave up to 24dB/Octave including Butterworth, Bessel, Linkwitz-Riley Gain Control, Noise Gate, Feedback Eliminator (Mic input only) per input channel Each output features a precision dynamic range controller composed of a Peak Limiter and a RMS Compressor with selectable ratio and variable knee Adjustable Delay time up to 380 mS per output channel |
| Direct PC/Network Connection | Front panel USB connector for direct PC communications Ethernet interface, RS485 connection for system setup, monitoring and control via manageable remote PC software |
| Control | Front panel interactive LCD display for local access and configuration Front panel 6-LED status indicators per channel 4 digital input ports for additional 4 preset selections withpriority configuration4 digital output ports for triggering external devices Simultaneous control up to 32 units via PC software DPA880xT software for Apple iPad® device allowing simultaneous control up to 32 units, setting all parameters and showing real time levels. Optional Marani CP4 Wall Panel control allowing selection of 4 assigned presets and master volume control Security Lockout |
Additional information
| Channel Input | 8 Channel |
|---|---|
| Pemrosesan Sinyal | Digital |
| Jumlah Zona | Tidak Ada |
| Fitur | NULL |
