LAB GRUPPEN D-40:4L

Description

Product Features

• 4,000 Watt amplifier with 4 flexible output channels and up to 2,000 Watts channel output
• Lake digital signal processing for unparalleled loudspeaker management and system control
• Integrated 8×8 channels of dual redundant Dante* digital audio networking with AES67 support
• 4 x 800 Watts into 2 Ohms, 4 x 1,000 Watts into 2.67 Ohms, 4 x 1,000 Watts into 4 Ohms, 4 x 1,000 Watts into 8 Ohms, 4 x 700 Watts into 16 Ohms, 4 x 500 Watts into Hi-Z 25 V, 4 x 1,450 Watts into Hi-Z 70 V, 4 x 2,000 Watts into Hi-Z 100 V
• Proven and reliable IDEEA Class D Output Stage with direct drive 70 and 100 V constant voltage systems as well as low impedance
• Rational Power Management (RPM) provides total flexibility to allocate available power across all 4 output channels for most efficient use of system inventory
• Best-in-class Power Factor Correction (PFC) and switch mode power supply reduces running costs and minimizes environmental impact
• Breaker Emulation Limiter (BEL) with configurable mains current draw threshold and breaker profile to safeguard mains breakers from tripping
• Configurable Auto Power Down and Adaptive Rail Control enables real world lifetime energy savings
• Under-Voltage Limiting (UVL) for continued operation during severe mains supply voltage drops
• Dedicated on-board surveillance and load monitoring for mass notification applications
• Redundant audio inputs and on-board system surveillance for voice alarm systems
• CAFE (Configuring Amplifiers For the Environment) software for design, system planning, equipment planning, installation and commissioning
• Control and monitoring integration with 3rd-party matrix systems including MediaMatrix* and Q-Sys* via dedicated interfacing software
• Dedicated front-panel mute buttons for each amplifier channel with bicolour LED indication
• 4 “Lake Class” analog input channels with Iso-Float ground isolation for reliable audio distribution
• 4 input channels of AES/EBU (AES3) digital audio supporting all standard sample rates up to 192 kHz with 24-bit resolution
• 2 Neutrik etherCON* RJ-45 ports provide dual redundant Dante interfaces and remote configuration via Lake Controller and Dante Controller software
• Balanced analog and digital audio inputs and amplifier outputs on plug-in Phoenix* connectors
• Detachable and locking IEC mains cable rated at 250 V / 16 A with variety of wall plugs selectable on order
• Removable dust filter grille for increased air circulation and simple maintenance
• Rugged slimline (1U) rackmount chassis including rear support brackets for ease of installation
• Designed and engineered in Sweden
