Description
The Pa300 is the latest keyboard in the KORG Pa series of internationally acclaimed and bestselling musical arrangers. It’s compact, inexpensive and powerful, with the most up-to-date collection of quality sounds and Styles. Using the built in Styles, you can quickly and easily play along with a backing band or even create your own music. The Pa300 is not only fun to play any time you like, but it’s the ideal way for people of all ages to write and perform music!
Fitur
- Enhanced RX (Real eXperience) sound engine offers improved realism and vivid sound
- Massive internal Factory PCM equivalent to the best-selling Pa600
- Elegantly designed and compact plastic cabinet includes a pristine amplification system
- 5” TouchView color TFT display
- Easy layout and intuitive graphical interface with Search function for easy retrieval of any musical resource or file
- Over 310 factory Styles, each including 3 Intros/Endings, 4 variations and 4 Fill In + Break, plus 8 Favorite and 3 User banks for storage of your favorite Styles. Enhanced Guitar Mode 2 provides even more realistic guitar parts.
- Improved GM set for Standard MIDI Files, MP3 player with Transpose and Tempo Change, compatibility with popular Lyric formats including graphical (+G), Text Viewer and Score.
- 4 Stereo Master Effects (125 FX algorithms)
- Fully programmable SongBook database based on Styles, SMF, Karaoke and MP3 files with instant recall of any song setting. User-definable custom lists, plus Filtering and Ordering options.
Spesifikasi
- Keyboard
- 61 keys
- Velocity sensitivity is supported
- System
- Upgradable Operating System
- RX (Real eXperience)
- Multitasking, Load while play feature
- Tone Generator
- 128 Voices, 128 Oscillators
- Filters with Resonance
- Three band EQ for each track
- Effects
- Up to 4 Stereo Digital Multi-Effect block systems
- 125 Master Effect types
- Master 4 band Parametric EQ
- Sounds / Drum Kits
- Factory:More than 950, including Stereo Piano and GM2 sound compatibility64 Drum KitsFull Sound and Drum Kit editing capability
- User:256 Sounds
- 128 Drum Kits
- Styles
- Factory:More than 310 Preload Styles Full Style editing capability
- User:Up to 1,040 available Style locations including the Favorite/User banks
- Structure:Eight Style tracks, 4 Single Touch Settings, 4 Pads, and one Style Performance per Style
- Style Controls:3 Intros, 4 Variations, 4 Fills, Break, 3 Endings, Auto fill, Synchro Start/Stop, Tap Tempo/Reset, Manual Bass, Bass Inversion, Memory, Accompaniment On/Off, Kick & Snare Designation
- Style Others:Guitar Mode 2, Parallel and Fixed NTT
- Performance / STS
- 240 Keyboard Performance locations, My Setting special Performance
- STS:Memorize Keyboard tracks – Up to 4 x 1040 Styles, up to 4 x SongBook entries
- Keyboard Tracks Four Keyboard tracks (Upper 1, 2, 3, Lower)
- Pads
- 4 Pad tracks + Stop button
- Full Pad editing capability Full Pad editing capability
- Song Play
- Player with select, Start/Stop, Home, Rewind and Fast Forward controls
- Jukebox function – Compatible with SMF (format 0 and 1) and MP3 – Lyrics (compatible with CGD), Score
- MP3 Player
- MP3 Player
- Transpose (+6/-5 semitones)
- Tempo change (±30%)
- Sequencer
- Quick Record (Backing Sequence)
- Multitrack and Step Record functions – Full-featured sequencer – 16 tracks – Up to 100,000 events
- SMF format
- SongBook Fully programmable music database, based on Styles, SMF, Karaoke, MP3 with automatic selection of Style Play and Song Play modes – User-definable custom lists – Filtering options
- SearchStyle, Song, Performance, SongBook, Sound and Lyrics TXT
- Compatibility
- “i-Series” models: Styles
- “Pa series” model Style, Performance, Sound, Song, SongBook, Pad
- General Controls Master Volume, Real Time-Acc/Seq Balance Volume, Ensemble, Upper Tracks Octave Transpose, Master Transpose, Tempo Lock, Quarter Tone Arabic Scale, User Scale memorized inside Performance/STS, Search, Lyrics, Score, Dial, Tempo, Metronome, Split, Joystick
- Connections
- Control Inputs:Assignable Pedal/Footswitch (Damper)
- Headphone/ Outputs:Unbalanced Stereo Jack
- MIDI USB to MIDI using the USB Device port – 8 user definable MIDI Presets
- USB
- USB-MIDI Interface
- Type A (TO DEVICE): 1 (Rear)
- Type B (TO HOST): 1 (Rear)
- 2.0 Hi Speed connections
- Mass Storage USB Memory Stick
- Display Color TouchView™ 5” (480 x 272 dots) TFT display
- Speaker System
- Amplification:13 W x 2
- Speakers;10 cm x 2 Double Cone Speakers in Bass Reflex Box
- Power
- Power Supply:AC 100-240 V
- Power Consumption:18 Watt
- Dimensions (W x D x H)1,030 x 378.3 x 127 mm / 40.55 x 14.89 x 5.00 inches (without music stand);
- Weight 8.35 kg / 18.41 lbs
- Accessories
- Quick Guide, Music Stand, External Power Supply Adapter and Power Cable
- *Accessory Disc including Video manuals, PDF manuals, USB-MIDI Drivers has been removed since June 2020.
- Please see here for the video manuals.
https://www.korg.com/products/synthesizers/pa300/page_3.php - For other items, please download from here.
https://www.korg.com/us/support/download/product/0/359/
- Options
- EXP-2 – Expression/Volume Pedal
- XVP-10 – Professional Expression/Volume Pedal
- DS-1H – Damper Pedal
- PS-1/PS-3 Switch Pedal
* All product, company, and standard names are trademarks or registered trademarks of their respective holders.
* Appearance and specifications of products are subject to change without notice.
Spesifikasi
Keyboard | 61 keys, velocity sensitive |
System | Upgradable operating system RX (Real eXperience) Multitasking, load while play feature |
Tone Generator | 128 Voices, 128 Oscillators Filters with resonance 3-band EQ for each track |
Effects | Up to 4 stereo digital multi-effect block systems 125 Master effect types Master 4-band parametric EQ |
Sounds | Factory 950+ (including Stereo Piano and GM2 sound compatibility) 64 Drum kits User 256 128 Drum kits |
Styles | Factory 310+ User Up to 1,040 locations including the Favorite/User banks Structure 8 x Style tracks 4 x Single Touch Settings (STS) 4 x Pads 1 x Style Performance per Style Style Controls 3 x Intros 4 x Variations 4 x Fills 1 x Break 3 x Endings Auto fill Synchro Start/Stop Tap Tempo/Reset Manual Bass Bass Inversion Memory Accompaniment On/Off Kick and Snare Designation Style Others Guitar Mode 2 Parallel and Fixed NTT |
Performance | Performance 240 x Keyboard Performance locations 1 x My Setting special Performance STS Memorize keyboard tracks – up to 4 x 1040 Styles, up to 4 x SongBook entries |
Tracks | 4 x Keyboard tracks (upper 1, 2, 3, lower) |
Pads | 4 x Pad tracks + stop button |
Song Play | Player with select, start/stop, home, rewind and fast forward controls Jukebox function – compatible with SMF (format 0 and 1) and MP3 – lyrics (compatible with CGD), score |
MP3 Player | MP3 player Transpose +6/-5 semitones Tempo change +/-30% |
Sequencer | Quick record (backing sequence) 16-track, full-featured sequencer with multitrack and step record functions, up to 100,000 events SMF format |
SongBook | Fully programmable music database, based on Styles, SMF, Karaoke, MP3 with automatic selection of Style Play and Song Play modes User-definable custom lists with filtering options |
Search | Style Song Performance SongBook Sound and Lyrics TXT |
Compatibility | i-Series: Styles Pa Series: Style, Performance, Sound, Song, SongBook, Pad |
Controllers | Master volume Real time-Acc/Seq balance volume Ensemble Upper tracks octave transpose Master transpose Tempo lock Quarter tone Arabic scale User scale memorized inside Performance/STS Search Lyrics Score Dial Tempo Metronome Split Joystick |
Connectors | 1 x 1/4″ TRS Main Output/Headphones 1 x 1/4″ TRS Pedal Input (pedal not included) 1 x USB Type A 1 x USB Type B |
MIDI | USB to MIDI using the USB device port – 8 user definable MIDI presets |
Storage | USB memory stick |
Amplifier | 2 x 13 W |
Speakers | 2 x 3.9″ (100 mm) double cone speakers in bass reflex box |
Display | 5″ Color TouchView TFT display (480 x 272 dots) |
Power Requirements | 100~240 VAC 18 W power consumption |
Dimensions (WxHxD) | 40.6 x 14.9 x 5.0″ (1030 x 378 x 127 mm) without music stand |
Weight | 18.4 lb (8.4 kg) |
Packaging Info
Package Weight | 28.55 lb |
Box Dimensions (LxWxH) | 36 x 26.5 x 11.2″ |
