CANARE L2T2S Kabel Audio Balanced Isi 3

Cek Harga
Share atau Bagikan :

Description

Canare’s thinnest profile audio hookup wire. Amazingly flexible, with 100% foil shield, drain wire and PVC jacket that strips easily for rapid assembly. Suitable for large cable harness bundles, mixing consoles, tape machines and inner-rack wiring.

●  Microphones.
●  Permanent Installations.
●  Audio Patch Cords.
●  PA Systems.
●  Post Production Suites.
●  Recording Studios.
●  100% Foil Shield Coverage w/Drain Wire.
●  Built in Dupont® Kevlar 29 and Drain Wire.
●  Cross Linked PE Insulation.
●  Reduced Handling Noise.
●  Rejects EMI and RFI.

Spesifikasi

Applications Microphones, portable applications, audio patch cords, and PA systems
Mechanical/Electrical
Outer Diameter Nominal: 0.236″ (6 mm)
Thickness Jacket: 0.039″ (1 mm)
Insulator: 0.77″ (19.7 mm)
Number of Conductors 2
Insulation Type: IPE
Note: Dielectric Strength: 500 VAC / per minute
Insulation Resistance: 1000 MOhms per 3′ (0.91 m)
Conductor D.C.R. Less than 19.8 Ohms / 1000′ (less than 6.5 Ohms / 100 m)
Shield D.C.R Less than 9.4 Ohms / 1000′ (less than 3.1 Ohms / 100 m)
Nominal Capacitance Between Conductors: 22 pF / ft (70 pF / m)
Between Conductors & Shield: 33 pF/ ft (106 pF / m)
Nominal Impedance 88 Ohms
Nominal Attenuation 0.9 V / 1000′ (0.3 V / 100 m)
Group Delay Time 1.83 ns / ft (6 ns / m)
Brittle Point -56°F (-49°C)
Length 656′ (200 m)
Weight 20 lb (9 kg)
Packaging Info
Package Weight 21.5 lb
Box Dimensions (LxWxH) 11.4 x 11.4 x 8.9″
