AUDIOCENTER Artist T8800
Class D amplifier
100% ORIGINAL
HARGA Kompetitif
GARANSI Resmi
AFTERSALES Service
Description
Artist T8800 professional power amplifier adopt switching power supply and class D circuit design which has good performance with high efficiency, light weight and good stability.
8-channel Artist T8800. It’s 400W each channel at 8Ω. Each channel can work stably at 4Ω.
Artist T8800 adopt modular design. Two channels share one power supply system and amplification system. With elaborately selected components and state-of-the-art craftwork, Artist T8800 have very good fidelity and high damping factor. It’s good choice for music reproduction, speech and AV system integration.
Specifications
|
Output Power（1kHz 20ms Burst THD+N=1%） |
8Ω Stereo |
8x400W |
|
4Ω Stereo |
8x800W |
|
|
8Ω Bridge |
4x1600W |
|
|
Protection System |
DC protection / Short circuit protection / Smart overheat management / Overheat protection / Input overload protection /Output overload protection / Soft startup protection / Limiter protection |
|
|
Working mode |
Stereo,Parallel,Bridge |
|
|
Input Connectors |
2×12-pin Euroblock（3.81mm） |
|
|
Output Connectors |
4×4-pin Euroblock（5.08mm） |
|
|
Input Impedance |
Balanced ≥20kΩ/ Unbalanced ≥10 kΩ |
|
|
Maximum input voltage |
≥20dBu |
|
|
Gain |
Stereo/Parallel：32dB；Bridge：38dB |
|
|
Frequency response(1W 8Ω stereo) |
20Hz-20kHz（±0.5dB） |
|
|
Crosstalk(1kHz, Rated power 8Ω, A weighted) |
≥60dB |
|
|
S/N Ratio(Rated power 8Ω, A weighted) |
≥108dB |
|
|
Damping Factor (1kHz&8Ω) |
≥500 |
|
|
Intermodulation Distortion(60Hz:7kHz=4:1, half power) |
≤0.05% |
|
|
Total Harmonic Distortion(1kHz, half power 8Ω, A weighted) |
≤0.05% |
|
|
Amplifier Type (Output Circuitry) |
Class D |
|
|
AC Power |
100-130V/220-240V(±10%,50-60Hz) |
|
|
Power consumption（1/8 output power） |
720W |
|
|
Rack space |
2U |
|
|
Cooling |
Fan cooling, blowing from front to back |
|
|
Dimension(W×H×D) |
483×88×410mm |
|
|
Net Weight |
11.5kg |
|
