Description

THA-6 is really ideal for applications such as recording, broadcast and Live events. It is a very flexible tool allowing
personal headphone mix for up to six musicians.

Fitur

  • Mountable in a 19″ Rack Unit
  • 6 individual headphone channels
  • Input gain control, and individual output gain control
  • Up to 3 headphone outputs per channel for a total of 18 headphones
  • Direct In and Headphone Output on the front panel for easy operation, when mounted in a rack
  • Input and Output Level Led Meter
  • Balance Control to mix up the Main In and the Aux In signal
  • Main Outputs for linking additional THA-6 headphone amplifiers
  • High-end quality even at high volume levels
  • Exceptionally rugged construction ensures long life and durability
  • Universal and professional headphone amplification system for studio and stage application
  • Manufactured under QS9000 certified quality system



Spesifikasi

Model THA-6 6 CHANNEL HEADPHONE AMPLIFIER
Main Input Connectors: XLR and 1/4″ jack
Type: HF filtered, servo balanced input
Impedance: 50 kOhms balanced, 25 kOhms unbalanced
Max.input level: +21 dBu balanced and unbalanced
CMRR: typ.40 dB, >55 dB @ 1kHz
AUX IN andDIRECT IN input Connectors: 1/4″ TRS (tip=left, ring=right, sleeve=ground)
Type: Unbalanced
Impedance: 25 kOhms Unbalanced
Max.input level: +21 dBu unbalanced
CMRR: typ,40 dB, >55 dB @ 1 kHz
OUTPUT Connectors: XLR and 1/4″ Jack
Type: Balanced /Unbalanced
Impedance: Dependent on the input impedance
Max. output level: +21 dBu Balanced and Unbalanced
SYSTEMSPECIFICATIONS Frequency response: 10 Hz to 50 kHz,+/-3 dB
Noise: >90 dB, Unweighted, 22 Hz to 22 kHz(>95 dB@+4 dBu)
THD: 0.005% typ.@+4 dBu, 1kHz, Gain 1
POWER AMPLIFIER Max.output power: +21 dBm
Min.output impedance: 100 Ohms
MAX. Gain: +20dB
FUNCTIONCONTROLS Input level: Variable
Balanced per channel: Mix between aux and main signal
Output level per channel: Variable
FUNCTIONSWITCHES Left mute: Mute left signal of the respective channel
Right mute: Mute right signal of the respective channel
Mode: Switch channel to mono
INDICATORS Input level: 8-digit LED display:-24/-18/-12/-6/0/+6/+12/+18dBu
Output level: 4-digit LED display:-24/0/+12/CLIP
POWER SUPPLY Mains voltage: USA/Canada: 120V~, 60Hz – UK/Australia: 240V~,50Hz – Europe: 230V~,50Hz
Power consumption: 40 W
Mains connection: Standard IEC receptacle
Fuse: 95-120V~: T500mA L/210-240V~: T315mA L
PHYSICAL Dimension (WxDxH): 483 x 217 x 44mm (19″ x 8.84″ x 1.7″)
Net weight: 2.9kg/6.39 lbs
