TOPP PRO Mxi6FX Mixer Analog 6 Channel

Mixer Analog 6 Channel

Chat Penjual
Category: Tags: , , , , , , , , , , , , Brand:
Topp Pro
Pengiriman Cepat

100% ORIGINAL

Pengiriman Cepat

HARGA Kompetitif

Pengiriman Cepat

GARANSI Resmi

Pengiriman Cepat

AFTERSALES Service

Description

MXi6.FX mixing console is a remarkable compact mixing desk that does not find many equals in the market today. With 2 microphone and 2 stereo Line-level inputs for small live performances, small studio recording and general PA applications, MXi6.FX also includes a 24-Bit digital multi-effect with 16 Factory Presets and separate level for digital reverb. There is a 3- band EQ on all input channels and separate Main Mix and Control Room outputs for operation with different volume settings. Use it for small GIGs and RECORDING. MXi6.FX also is a flexible tool for Multimedia presentations.

Fitur

  • 2 MIC input channels with gold plated XLR and balanced LINE input
  • 2 stereo input channels with balanced TRS jacks
  • Ultra-low noise discrete MIC pre-amps with +48V Phantom power
  • Extremely high headroom offering extra dynamic range
  • Balanced inputs for optimal signal integrity
  • Warm, natural 3-band EQ on each channel
  • Built-in 24 bits digital effects processor
  • Peak LED on each channel
  • AUX send for internal effects or stage monitoring
  • Main output, Control room and headphone outputs
  • 2-Track inputs assignable to main mix, control roomvheadphone outputs
  • Highly accurate 4-segment bar graph meters



Spesifikasi

Model MXi.6FX
Input Channels
Mono input channels
Microphone input electronically balanced, discrete input configuration
Frequency response 10 Hz to 55 kHz, +/ 3 dB
Distortion (THD & N) 0.005% at +4 dBu, 1 kHz
Gain range 0 dB to 60 dB (MIC)
SNR (Signal to Noise Ratio) 115 dB
Line input electronically balanced
Frequency response 10 Hz to 55 kHz, +/ 3 dB
Distortion (THD & N) 0.005% at +4 dBu, 1 kHz
Stereo input channels
Line input Balanced
Frequency response 10 Hz to 55 kHz, +/- 3 dB
Distortion (THD & N) 0.005% at +4 dBu, 1 kHz
Impedance
Microphone Input 1.4 k Ohms
All Other Input 10k Ohms or Greater
Tape Out 1k Ohms
All Other Outputs 120 Ohms
Equalization
Hi shelving +/- 15 dB @12 kHz
Mid bell +/- 15 dB @ 2.5 kHz
Low shelving +/- 15 dB @ 80 Hz
DSP Section
A/D and D/A converters 24-bit
DSP resolution 24-bit
Type of effects Vibraflange, Funky, Rockabilly, Bigstage, Vibrato1-4,Flanger1-4, Chorus1-4
Presets 16
Controls 16-position PRESET Selector, FX level, REVERB level, CLIP LED
Main Mix Section
Noise (Bus Noise) Fader 0dB,Channels muted:-100dBr (ref:+4dBu)
Fader 0dB, All Input Channels Assigned and Set To UNITY Gain:-90dBr(ref:+4dBu)
Max Output +22 dBu Unbalanced,1/4′ Jacks
AUX Sends max out +22 dBu
AUX Returns gain range 8 to +15 dB
Power Supply(AC/DC Adaptor)
Main voltage USA / Canada 100-120 V~, 60 Hz
Fuse Europe 210-230 V~, 50 Hz, U.K. / Australia 240 V~, 50 Hz
Power Consumption 15 Watts
Physical
Dimension (W D H) 185 mm x 230 mm x 35/55 mm
Net weight 1.4 Kg (3.09 lb)
Shipping weight 2.7 Kg (5.95 lb)
