TOPP PRO Mxi6FX Mixer Analog 6 Channel

Mixer Analog 6 Channel

Chat Penjual

100% ORIGINAL

HARGA Kompetitif

GARANSI Resmi

AFTERSALES Service

Description
Additional information

Description

MXi6.FX mixing console is a remarkable compact mixing desk that does not find many equals in the market today. With 2 microphone and 2 stereo Line-level inputs for small live performances, small studio recording and general PA applications, MXi6.FX also includes a 24-Bit digital multi-effect with 16 Factory Presets and separate level for digital reverb. There is a 3- band EQ on all input channels and separate Main Mix and Control Room outputs for operation with different volume settings. Use it for small GIGs and RECORDING. MXi6.FX also is a flexible tool for Multimedia presentations.

Fitur

2 MIC input channels with gold plated XLR and balanced LINE input
2 stereo input channels with balanced TRS jacks
Ultra-low noise discrete MIC pre-amps with +48V Phantom power
Extremely high headroom offering extra dynamic range
Balanced inputs for optimal signal integrity
Warm, natural 3-band EQ on each channel
Built-in 24 bits digital effects processor
Peak LED on each channel
AUX send for internal effects or stage monitoring
Main output, Control room and headphone outputs
2-Track inputs assignable to main mix, control roomvheadphone outputs
Highly accurate 4-segment bar graph meters

Spesifikasi

Model

MXi.6FX

Input Channels

Mono input channels
Microphone input	electronically balanced, discrete input configuration
Frequency response	10 Hz to 55 kHz, +/ 3 dB
Distortion (THD & N)	0.005% at +4 dBu, 1 kHz
Gain range	0 dB to 60 dB (MIC)
SNR (Signal to Noise Ratio)	115 dB
Line input	electronically balanced
Frequency response	10 Hz to 55 kHz, +/ 3 dB
Distortion (THD & N)	0.005% at +4 dBu, 1 kHz
Stereo input channels
Line input	Balanced
Frequency response	10 Hz to 55 kHz, +/- 3 dB
Distortion (THD & N)	0.005% at +4 dBu, 1 kHz

Impedance

Microphone Input	1.4 k Ohms
All Other Input	10k Ohms or Greater
Tape Out	1k Ohms
All Other Outputs	120 Ohms

Equalization

Hi shelving	+/- 15 dB @12 kHz
Mid bell	+/- 15 dB @ 2.5 kHz
Low shelving	+/- 15 dB @ 80 Hz

DSP Section

A/D and D/A converters	24-bit
DSP resolution	24-bit
Type of effects	Vibraflange, Funky, Rockabilly, Bigstage, Vibrato1-4,Flanger1-4, Chorus1-4
Presets	16
Controls	16-position PRESET Selector, FX level, REVERB level, CLIP LED

Main Mix Section

Noise (Bus Noise)	Fader 0dB,Channels muted:-100dBr (ref:+4dBu)
Noise (Bus Noise)	Fader 0dB, All Input Channels Assigned and Set To UNITY Gain:-90dBr(ref:+4dBu)
Max Output	+22 dBu Unbalanced,1/4′ Jacks
AUX Sends max out	+22 dBu
AUX Returns gain range	8 to +15 dB

Power Supply(AC/DC Adaptor)

Main voltage	USA / Canada 100-120 V~, 60 Hz
Fuse	Europe 210-230 V~, 50 Hz, U.K. / Australia 240 V~, 50 Hz
Power Consumption	15 Watts

Physical

Dimension (W D H)	185 mm x 230 mm x 35/55 mm
Net weight	1.4 Kg (3.09 lb)
Shipping weight	2.7 Kg (5.95 lb)

Additional information

Channel Input	6 Channel
Pemrosesan Sinyal	Analog
Jumlah Zona	Tidak Ada
Fitur	NULL
