Description
The new TOPP PRO MUSIC GEAR KS ARRAY series cabinets have been Designed to provide a cost effective high grade solution while maintaining high quality construction and optimum components.
The KS ARRAY series is designed light weight powered loudspeaker systems and all new class D power amplifiers.
KS 218A SUB use 2000 Watt continuous class D power module. This series also breaks from the traditional loudspeaker paradigm, every model is fit with the identical 1.4” voice coil Compression Driver and woofer of high quality for unparalleled performance, regardless of speaker size. Extensive DSP processing is employed throughout, providing levels of sonic clarity and total output that defy the system’s size and weight. Premium-grade materials, advanced construction processes and multiple mounting and suspension options allow for a wide range of live and installed applications. Great pride & care is placed in delivering products with excellent performance, specifications, and dependable reliability.
Fitur
- 650W ClassD BI-AMP for KST28A, 2000W for KS 218A SUB, 3000W for KS LT118A SUB.
- Connectors: Input: Left Mono (Combo) / Right (XLR-F) / Output: Left Mono/ Right (XLR-M),
Link-Left/ Mono-Right (XLR-M) Balanced 15 KOhms. - Volume control / Power ON with green LED Clip limiter with Red LED/ Ground lift/ 1P Control Module (Optional).
- Protections: Thermal / Convection Fan/ Overload Digital Lim / Compressor.
- Neutrik POWER CON® connector, 110-120V/220-240V-50/60Hz Switchable.
- Plywood cabinet, resistant black paint, metal grille with foam, KS T28A, KS 218A SUB has double handle.
- KS LT118A SUB has four handle.
- One metal standard pole-mount.
Spesifikasi
| Model Active | KS 218A SUB |
| System Type | Active subwoofer |
| Power Rating | 4000W (PROGRAM) / 8000W (PEAK) |
| Transducer Low | 2 x 18″ Woofer, 3″ Sandwich Voice Coil with long excursion |
| Max SPL | 133dB Max. |
| Active Crossover | BandPass type 12dB/oct. under analog processor |
| Frequency Response (-6dB) | 35Hz – 120Hz under analog processor |
| Input Connector | In-Left / Mono (COMBO) Right (XLR-F) / Out-Left / Mono Right (XLR-M) / Link-Left / Mono-Right (XLR-M) Balanced (15KOhms) |
| External Controls | Volume Control / Phase Switch / HPF-80Hz for L-R Satellite or By Pass / Power ON with Green LED / Clip Limiter with Red LED / Ground Lift |
| Electronic Protections | Thermal / Convection-Fan / Overload / Lim. / Compressor |
| Power Supply | 110-120V~50/60Hz or 220-240V~50/60Hz Switchable |
| Enclosure Construction | Plywood cabinet, metal grille, rubber foot |
| Mounting | One metal standard pole-mount |
| Dimensions (HxWxD) | 535 x 518.5 x 1000mm (21.06″ x 20.41 x 52.36″) |
| Net Weight | 46.64kg / 102.82Ibs |
| Volume | 15.887CFT |
