Tascam DR-10L Micro Recorder with Lavalier Microphone
Description
Go where the action is with the TASCAM DR-10L. This lightweight, ultra-compact digital audio recorder features a discreet lavalier microphone, making it ideal when the situation calls for a bit of stealth. Mount a DR-10L on an actor during a location shot, and leave your boom mic at home. Make a great-sounding wedding video. Create a presentation video with professional audio quality. Dual recording with different audio levels prevents an unexpected loud moment from ruining your recording. Automatic leveling and limiting prevent distortion caused by overloads. Automatic file closing saves your data before your battery runs out. The TASCAM DR-10L digital audio recorder is a wonderful problem solver!
Compact recorder for those difficult stealthy affairs
TASCAM combined their popular mini-recorder with a high-performance lavalier mic to create a super-discreet recording system. Weighing in at around two ounces, the DR-10L is a cinch to conceal. Place it invisibly on your on-camera talent. Ensure that every word of your documentary subject, presenter, or even an entire wedding party is captured with excellent quality – no complicated wireless system required. At Sweetwater, we’ve found that the DR-10L is easy to use, easy to wear, and a total lifesaver in stealthy situations.
Dual recording, automatic level, and limiting prevent common problems
Here’s the situation: you placed a lav mic on your actor. You checked your levels carefully. Things are going great. Then the actor decides to scream one of his lines. Or maybe your documentary subject did something unexpected. (That never happens, right?) The TASCAM DR-10L’s dual recording feature solves this problem by capturing two separate files at different levels. Automatic level and limiter functions are also onboard. The leveler increases or decreases your recording volume to the appropriate level. The limiter prevents distortion caused by unexpected input overloads. Even with very little effort, the DR-10L guarantees a quality recording.
Automatic file closing saves file data before the battery runs out
Even though the TASCAM DR-10L operates for up to 10 hours on a single AAA battery, disaster can still befall you. Imagine that you’re in the middle of an event. The recording is going great. Then the battery runs out. It’s bad enough that you have to stop recording, but even worse – you lost all of your data. The first half of the event is gone forever! The DR-10L’s automatic file closing function rescues you from this embarrassing predicament by saving your file data before the battery runs out. Also, the DR-10L’s case is designed for fast battery changes, so even after your battery runs out, you’ll get back up and running in no time.
Features at a glance
- Micro-sized audio recorder with lavalier microphone, microphone clip and windscreen included (cable length: 160 cm)
- Records to microSD/microSDHC card (up to 32 GBytes)
- Linear PCM mono/poly recording at 44.1/48 kHz, 16/24 bits
- BWF-compatible WAV format allows inclusion of time information within audio files
- Recording and playback of MP3 format files
- Sampling rate: 44.1/48 kHz, resolution: 16/24 bits
- Bit rate: 128/192 kbit/s (recording), 32–320 kbit/s (playback)
- Switchable limiter to prevent clipping
- Switchable low-cut filter to reduce low-frequency noise
- Low/Mid/High/High+ recording level settings
- Automatic level control available
- Dual recording function allows two files to be recorded simultaneously at different levels to provide a safety track in case of distortion (level reduction for secondary recording selectable –6/–12 dB )
- Sliding record switch and hold function to prevent misoperation during recording
- Automatic file closing function to prevent the loss of already recorded data
- Built-in clock function, supports BWF files with included time information – convenient for editing and searching
- Time track incrementing function can create new files at regular intervals (about every 15 minutes) during recording
- Playback function allows recorded data to be checked immediately
- Headphones output
- High-contrast, easy-to-read OLED display
- Micro USB-B connector for easy data transfer with a computer
- Records at least 10 hours on a single AAA battery using alkaline batteries (Evolta)
- Settings can be created as a text file on a computer and transferred to the recorder via USB
- Firmware can be updated using a microSD card
- Belt clip included
- Custom case for storing the unit and accessories included
Spesifikasi
| Recording media | microSD card (64MB to 2GB), microSDHC card (4GB to 32GB) |
| Media discharging | Push-Push type (Guard cover mounted) |
| Recording format | |
| V1.00 | |
| WAV | 44.1k/48k Hz, 16/24-bit mono/poly WAV (BWF format) |
| V2.00 | |
| WAV | 44.1k/48k Hz, 16/24-bit mono/poly (BWF format) |
| MP3 | 44.1k/48k Hz, 24-bit mono/poly |
| Recording | 128k/192k bps |
| Playback | 32k to 320k bps |
| Analog audio Inputs | |
| Connector | 1/8″ (3.5mm) TRS jack with screw lock |
| Microphone sensitivity | –42dBV/Pa |
| Maximum input sound pressure | 115dB SPL |
| Maximum input level | –15dBu (Gain L) |
| Minimum input level | –55dBu (Gain H+) |
| MIC input gain | +14dB to +38dB |
| Input impedance | 33kΩ (Mic bias off)/ 2kΩ (Mic bias on) |
| PHONES | |
| Connector | 1/8″ (3.5mm) stereo mini jack (Dual Mono Output) |
| USB | |
| Connector | Micro-B type 4pin |
| Protocol | USB2.0 HIGH SPEED mass storage class |
| Power | 1 AAA battery (Alkaline battery/ Ni-MH battery / Lithium battery), USB bus power |
| Power consumption | 0.45W |
| Battery operation time | WAV, 48kHz, 24-bit Rec, without headphones, limiter: OFF , Dual Rec: OFF, JEITA Rec *All times are approximate. |
| Alkaline battery (EVOLTA) | 10 hours |
| Ni-MH battery (eneloop) | 8 hours |
| lithium battery (Energizer ULTIMATE LITHIUM) | 15.5 hours |
| Battery (RTC) | Lithium × 1(built in with soldering) |
| Dimensions (W×:H×D) | 2.05″ × 2.19″ × 0.96″ / 52 × 55.6 × 24.4 mm |
| Weight | 2.2 oz. / 63 g (including battery) 1.8 oz. / 51g (excluding battery) |
| Operating temperature | 32˚F to 104˚F / 0˚C to 40˚C |
| Accessories | Lavalier microphone with microphone clip and windscreen, USB cable (A type-micro B type), Belt clip, Custom case for storing the unit and accessories included, Owner’s manual (including warranty) |
