Shure MX415 38,1 cm Gooseneck Microphone
Gooseneck (38,1 cm) microphone with Bi-Color LED status or light ring display
100% ORIGINAL
HARGA Kompetitif
GARANSI Resmi
AFTERSALES Service
Description
The MX415 surface mount version is a gooseneck microphone with a Bi-Color LED or light ring status display. It has a 38,1 cm gosseneck and is suitable for boardrooms and other sites where aesthetics are important.
MAIN FEATURES
TECHNICAL SPECIFICATIONS
Weight: 70 g
Frequency Response: 50 Hz – 17 kHz
Frequency Response: Tailored
Equivalent Selfnoise: Cardioid: 28 dB(A), Supercardioid 27 dB(A)
Sound Pressure: Cardioid: 121 dB , Supercardioid: 120 dB
Transducer Type: Condenser
Polar Pattern: Cardioid
Switchable low cut: No
Connectors: 3 Pin XLR
Attenuator: No
Interchangeable Capsule: Yes
Main Functionality: Installed
Headphone Output: No
Requires Phantom Power: 48-52 VDC VDC
Cartridge: Interchangeable
FURTHER TECHNICAL SPECIFICATIONS
- Output Impedance: EIA Rated at 150 Ω (170 Ω actual)
- Sensitivity (at 1 kHz , open circuit voltage):
- Cardioid-35dBV/Pa / 18mV/Pa;
- Supercardioid-34dBV/Pa / 21mV/Pa
- Maximum SPL (1 kHz at 1% THD, 1 kΩ load)
- Cardioid: 121 dB
- Supercardioid: 120 dB
- Equivalent Output Noise (A-weighted)
- Cardioid: 28 dB SPL
- Supercardioid: 27 dB SPL
- Signal-to-Noise Ratio (referenced at 94 dB SPL at 1 kHz)
- Cardioid: 66 dB
- Supercardioid: 68 dB
- Dynamic Range (1 kΩ load at 1 kHz): 93 dB
- Common Mode Rejection (10 Hz to 100 kHz): 45 dB minimum
- Preamplifier Output Clipping Level (1% THD): –8 dBV (0.4 V)
- Polarity
- 3-Pin XLR: Positive sound pressure on diaphragm produces positive voltage on pin 2 relative to pin 3 of output XLR connector.
- 5-Pin XLR: Positive sound pressure on diaphragm produces positive voltage on pin 4 relative to pin 2 of output XLR connector.
- Logic Connections
- LED IN: Active low (≤1.0V), TTL compatible. Absolute maximum voltage: -0.7V to 50V.
- LOGIC OUT: Active low (≤1.0V), sinks up to 20mA, TTL compatible. Absolute maximum voltage: -0.7V to 50V (up to 50V through 3kΩ).
- Mute Switch Attenuation: –50 dB minimum
- Environmental Conditions
- Operating Temperature: -18–57 °C (0–135 °F)
- Storage Temperature: -29–74 °C (-20–165 °F)
- Relative Humidity: 0–95%
- Power Requirements: 48–52 Vdc phantom, 8.0 mA
