Shure MX405 12,7 cm Gooseneck Microphone
Shure MX405 12,7 cm Gooseneck Microphone - Image 2

Shure MX405 12,7 cm Gooseneck Microphone

Gooseneck (12,7 cm) microphone with Bi-Color LED or light ring status display

Chat Penjual
Categories: , Tags: , , , , , , Brand:
Shure
Pengiriman Cepat

100% ORIGINAL

Pengiriman Cepat

HARGA Kompetitif

Pengiriman Cepat

GARANSI Resmi

Pengiriman Cepat

AFTERSALES Service

Description

The MX405 is a gooseneck microphone with a Bi-Color LED or red light ring status display. It has a 12.7 cm / 5 inch gooseneck and is suitable for boardrooms and other sites where aesthetics are important.



TECHNICAL SPECIFICATIONS

Weight: 54 g
Frequency Response: 50 Hz – 17 kHz
Frequency Response: Tailored
Equivalent Selfnoise: Cardioid: 28 Supercardioid 27 dB(A)
Sound Pressure: Cardioid: 121 dB , Supercardioid: 120 dB
Transducer Type: Condenser
Polar Pattern: Cardioid
Switchable low cut: Yes
Connectors: 3 Pin XLR
Attenuator: No
Interchangeable Capsule: Yes
Main Functionality: Installed
Headphone Output: No
Requires Phantom Power: 48-52 VDC VDC
Cartridge: Interchangeable

FURTHER TECHNICAL SPECIFICATION

  • Sensitivity (at 1 kHz , open circuit voltage):
    • Cardioid-35dBV/Pa / 18mV/Pa;
    • Supercardioid-34dBV/Pa / 21mV/Pa
  • Output Impedance: EIA Rated at 150 Ω (170 Ω actual)
  • Maximum SPL (1 kHz at 1% THD, 1 kΩ load)
    • Cardioid: 121 dB
    • Supercardioid: 120 dB
  • Equivalent Output Noise (A-weighted)
    • Cardioid: 28 dB SPL
    • Supercardioid: 27 dB SPL
  • Signal-to-Noise Ratio (referenced at 94 dB SPL at 1 kHz)
    • Cardioid: 66 dB
    • Supercardioid: 68 dB
  • Dynamic Range (1 kΩ load at 1 kHz): 93 dB
  • Common Mode Rejection (10 Hz to 100 kHz): 45 dB minimum
  • Preamplifier Output Clipping Level (1% THD): –8 dBV (0.4 V)
  • Polarity
    • 3-Pin XLR: Positive sound pressure on diaphragm produces positive voltage on pin 2 relative to pin 3 of output XLR connector.
    • 5-Pin XLR: Positive sound pressure on diaphragm produces positive voltage on pin 4 relative to pin 2 of output XLR connector.
  • Logic Connections
    • LED IN: Active low (≤1.0V), TTL compatible. Absolute maximum voltage: -0.7V to 50V.
    • LOGIC OUT: Active low (≤1.0V), sinks up to 20mA, TTL compatible. Absolute maximum voltage: -0.7V to 50V (up to 50V through 3kΩ).
  • Mute Switch Attenuation: –50 dB minimum
  • Environmental Conditions
    • Operating Temperature: -18–57 °C (0–135 °F)
    • Storage Temperature: -29–74 °C (-20–165 °F)
    • Relative Humidity: 0–95%
  • Power Requirements: 48–52 Vdc phantom, 8.0 mA
