Samson SM10 Mixer Line Analog Stereo 10 Channel
10-channel Line Mixer with Aux Sends – 1U Rackmountable Design
Description
The Samson SM10 line mixer features ten channels with 1/4-inch stereo line inputs and a balance control for each channel, letting you blend the relative levels of stereo inputs to your liking. Each channel also offers a switch for +4 dBu or -10 dBV line level input. Two channels include combo mic inputs with low noise, discrete mic preamps with 48-volt phantom power. You also get electronically balanced main stereo XLR and 1/4-inch line outputs, as well as front panel headphone and monitor outputs with dedicated level controls.
The SM10 provides versatile signal routing via Main Mix, Mix B, Monitor and EFX bus outputs. Two auxiliary sends can also be used to route signals to external effects, or create a separate mix for on-stage monitors. The mix may be audited with the SM10’s 6-segment LED meter and a flexible meter/headphone source control.
- Ten channels (eight 1/4″ stereo line inputs, two combination XLR-1/4″ inputs)
- Balance control for each channel
- Switchable +4 dBu or -10 dBV line input level
- Balanced main stereo XLR and 1/4″ line outputs
- Versatile signal routing
- Low noise, discrete microphone preamplifiers with 48-volt phantom power
- Two auxiliary sends
- Front-panel headphone and monitor outputs with level controls
- Flexible 6-segment LED meter/headphone source control
- Center detents for all controls for use in low light situations
- Single 19″ rackmount metal chassis with internal power supply
Spesifikasi
| Inputs | 8 x 1/4″ Stereo Inputs 2 x XLR/TRS Combo Inputs |
| Outputs | 2 x Balanced 1/4″ Stereo Main Outputs 2 x Balanced XLR Stereo Main Outputs 1 x Main Mix Output 1 x Mix B Output 1 x EFX Bus Output 1 x Monitor Output 1 x Headphone Output |
| AUX Sends | 2 |
| Input Level | +4dBu/-10dBV, Switchable |
| Meter | 6-Segment LED Meter |
| Phantom Power | 48V |
| Dimensions (HxW) | 1.75 x 19″ (44 x 483mm), 1RU |
| Weight | Not Specified by Manufacturer |
| Package Weight | 8.1 lb |
| Box Dimensions (LxWxH) | 23 x 11.5 x 4.7″ |
