Neumann BCM 705 Dynamic Broadcast Microphone
Dynamic Studio Microphone with Hypercardioid Polar Pattern
Description
The BCM 705 is a cost effective microphone for broadcast and podcast applications. Its entire construction is functionally optimized to convey emotion with technical perfection. Its dynamic capsule is voiced for a smooth yet clear sound with excellent speech intelligibility. The hypercardioid pattern along with the internal shock mount and pop filter minimize extraneous noises.
Features
- Functionally optimized design
- Specially designed dynamic capsule
- Optimized for close speech
- Hypercardioid pattern
- Integrated pop screen and shock mount
- Headgrille twists off easily for quick cleaning
Spesifikasi
| Acoustical operating principle | Pressure gradient transducer |
| Directional Pattern | Hypercardioid |
| Frequency Range | 20 Hz … 20 kHz |
| Sensitivity at 1 kHz into 1 kohm | 1.7 mV/Pa = –55.4 dB ± 1 dB |
| Rated Impedance | 200 ohms |
| Rated load impedance | 10 kohms |
| Equivalent noise level, CCIR 1 | 32 dB |
| Equivalent noise level, A-weighted 2 | 18 dB-A |
| Signal-to-noise ratio, CCIR (re. 94 dB SPL) 3 | 62 dB |
| Signal-to-noise ratio, A-weighted (re. 94 dB SPL) 4 | 76 dB |
| Weight | 500 g |
| Diameter | 64 mm |
| Length | 85 mm |
| Height | 110 mm (without suspension) |
