Mipro AD 707 A reciver antenna divider / wideband mic
reciver antenna divider / wideband mic
100% ORIGINAL
HARGA Kompetitif
GARANSI Resmi
AFTERSALES Service
Description
Fitur
• Compatible with any 2~4 ACT-series receivers or other true diversity receivers. Four UHF diversity receivers can be operated from just a pair of antennas, greatly reducing antenna installations clutter and increasing receiving range and efficiency.
• Adopts the latest wide dynamic range and low noise component, advanced circuit design featuring very low inter-modulation distortion and eliminates the spurious interference in multiple system usage. System output gain equals to 1.
• It is compatible with any antennas within its wideband ranges like AT-20 Coaxial Antenna, AT-70 UHF Ground Plane Antenna and AT-90 Transmitting / Receiving Directional Wideband Antenna.
• The input antenna connector provides power for the optional AT-70B antenna booster and AT-90 Transmitting / Receiving Directional Wideband Antenna.
Spesifikasi
| Datasheet | AD-707 Datasheet [PDF] |
|---|---|
| Frequency Range | 620 – 960 MHz |
| Bandwidth | 32 MHz |
| IIP3 | +22 dBm |
| Input / Output Gain | +1.0 dB (center band) |
| Output Port Isolation | 15 dB min |
| Impedance | 50 Ω |
| Connector | TNC Female |
| Power Supply | 12 – 18 V DC |
| Current Consumption | Approx. 170 mA |
| Dimension (W × H × D) | 482 × 44 × 190 mm / 19 × 1.7 × 7.5 “ |
| Weight | Approx.1.5 kg / 3.3 lbs |
| Note | Refer to actual product in the event of product discrepancy. |
