Marani KD1550P Digital Karaoke Processor

Description

KD1550P is a high performance digital karaoke processor that allows independent control of audio processing on music sources, microphones and digital effects applied to the voice. It provides several inputs including 3 MICs, 2 stereo analog and 1 digital S/PDIF-Optical in addition to 5 outputs and 2 auxiliary outputs. All of these are managed by powerful MARANI® DSP. The microphone input section offers a complete set of functions for voice processing without modifying its original characteristics. It includes 10-band parametric EQ and Noise Gate in addition to Vocal Exciter function which provides amazing presence and brilliance to the singer’s voice.The input path also features a Feedback Eliminator with intensity adjustable to prevent feedback occuring during the performance.

For Microphone source, the KD1550P provides an effects section equipped with professional reverb and delay algorithms that allows the best effect/voice combination to be obtained through a full set of controls and mixing outputs. Furthermore, the delay section provides 3 independent delays selected as delay time and feedback in order to create particular effects. Looking at the Music input section, the KD1550P include 10-band Graphic Equalizer, Noise Gate and RMS Compressor. The output section provides 5 output, each of them include LP/HP, 4-band parametric equalizer, Peak Limiter and Delay up to 110ms. Furthermore, 2 auxiliary stereo outputs are used tomonitor either microphone signal from Pre/Post effects section or music signal from music input section. The KD1550P can be connected via USB by using the control remote PC SW setting all parameters and creating favorite presets. Moreover, it is equipped with wired and infrared remote control.

Fitur

Outstanding Performance

3 MIC inputs, 2 stereo line inputs, 1 digital input, 5 outputs and 2 auxiliary output with full matrix mixing
Excellent sonic performance with 24bit high end converters coupled with 48kHz sample rate

Microphone Input Section

10-band Parametric equalization and Noise Gate per channel
Vocal Exciter function for amazing presence per channel
Feedback Eliminator function based on a power ‘Pitch Shifting’ algorithm per channel
HP/LP filter per channel

Music Source Input Section

10-band Graphic Equalizer, Noise Gate and RMS Compressor

Audio Effects Section

Professional reverb and delay algorithms for best effect/voice combination through a full set of controls and mixing options
3 Independent delays selected as delay time and feedback in order to get particular effects

Output Section

5 Output paths including HP/LP filters, 4-band PEQ and Peak Limiter
Adjustable Delay time up to 110ms per output channel
Auxiliary stereo output used to monitor either microphone signal or music signal

Control

Front panel USB connector for direct PC communications via PC SW setting all parameters and creating favorite presets
Front panel interactive LCD display for local access and control
Wired and Infrared remote controls
