Mackie 1604VLZ4 Mixer Analog 16 Channel

16-ch Analog Mixer with 16 Onyx Mic Preamps, 4 x Aux Sends Per Channel, 4 x Mix Buses, and 8 x Direct Outputs

Cek Harga
Share atau Bagikan :

Description

the Mackie 1604VLZ4 mixer is one piece of gear you can truly rely on. It continues the VLZ Series’ trend for rock-solid construction, while taking your sound quality to a new level. You’ve got an amazingly wide dynamic range, incredible 60dB gain range on the Onyx microphone preamplifiers, and ultra-low-noise performance. The 1604VLZ4 also boasts better-than-ever RF rejection for prime performance in broadcast situations. And with high-resolution meters, generous I/O, and sealed rotary controls that keep out dust and grime, the Mackie 1604VLZ4 is one of Mackie’s best mixers ever.

VLZ4 Multi-Channel Compact Mixers

A legend in compact mixer design, performance, and durability, Mackie VLZ is the original no-nonsense mixer series. Offering more bang for your buck, the redesigned VLZ4 line now includes Mackie’s industry-proven Onyx preamps for crystal-clear sonic clarity. The comprehensive VLZ4 line delivers the proven feature set, high-headroom/low-noise design and ‘Built-Like-A-Tank’ construction that created an industry more than 20 years ago. From every input to every output, VLZ4 is optimized to deliver professional-quality results each and every time.

Maximum Usability

The new VLZ4’s feature a sleek black powder coat finish and cockpit-inspired controls. Colorful high-contrast knobs optimizes the VLZ4’s usability in low-light scenarios as well as feature a radical, ergonomic taper that provides all the tactile control you need all while keeping the mixer footprint as small as possible.

Built Like A Tank

Show to show the VLZ4 is made to keep on working no matter what gets thrown at it. Features like a nearly indestructible steel wrap-around chassis and grime-resistant rotary sealed pots make the Mackie VLZ4 mixer a solid investment.

Comprehensive Lineup

The comprehensive VLZ4 line offers mixers of every channel count for every application. From the 402VLZ4 which is perfect for desktop applications to the tour-ready 3204VLZ4 there is a VLZ4 mixer ready for any situation.

Mackie 1604VLZ4 Features

  • 16 great-sounding mic preamps
  • Balanced main outputs
  • Inserts per channel
  • RCA and 1/4″ inputs
  • Sweep mid EQ
  • Six AUX sends

Spesifikasi

Noise Main Mix Noise:
Main Mix Fader @ Unity, Channel Faders Down: -88.5 dBu (92 dB signal-to-noise ratio, ref +4 dBu)
Main Mix Fader @ Unity, Channel Faders @ Unity: -82.5 dBu
(20 Hz to 20 kHz bandwidth, 1/4″ main out, channel gains at unity, channel EQs flat, all channels assigned to main mix, odd channels panned left, even channels panned right)
Total Harmonic Distortion (THD) Microphone In to Insert Send: <0.0007%
Microphone In to Main Out: <0.005%
(1 kHz @ 35 dB gain, 20 Hz to 20 kHz bandwidth)
Crosstalk / Attenuation Channel Mute Switch Engaged: -84 dBu
Channel Gain Knob Down: -84 dBu
(1 kHz relative to 0 dBu, 20 Hz to 20 kHz bandwidth, line in, 1/4″ main out, gain @ unity)
Frequency Response Microphone Input to Main Output (Gain @ Unity):
+0, -1 dB, 20 Hz to 50 kHz
+0, -3 dB, <10 Hz to >100 kHz
Equivalent Input Noise 150 Ω Termination: -128.5 dBu, 20 Hz to 20 kHz
Microphone input to insert send out, maximum gain
Common Mode Rejection Ratio Better than -70 dB @ 1 kHz
Maximum Level Microphone In: +22 dBu
All Other Inputs: +22 dBu
Main Mix TRS Out: +28 dBu
All Other Outputs: +22 dBu
Impedance Microphone In: 2.5 kΩ
Channel Insert Return: 2.5 kΩ
All Other Inputs: 10 kΩ or greater
Tape Out: 1.1 kΩ
All Other Outputs: 120 Ω
Equalizer High Shelving: ±15 dB @ 12 kHz
Mid Peaking: ±15 dB sweep 100 Hz to 8 kHz
Low Shelving: ±15 dB @ 80 Hz
Low Cut Filter: 18 dB/octave, -3 dB @ 75 Hz
Power Consumption 50 W, 100 to 120 VAC, 50 to 60 Hz
Operating Temperature 32 to 104°F (0 to 40°C)
Fuse Rating 100 to 120V: 1 A slo blo, 5 x 20 mm
220 to 240V: 0.5 A slo blo, 5 x 20 mm
Dimensions (H x W x D) 17.0 x 17.3 x 5.1″ (433.0 x 440.0 x 129.0 mm)
Weight 20.0 lb (9.1 kg)
Packaging Info
Package Weight 29.2 lb
Box Dimensions (LxWxH) 21.0 x 21.0 x 10.0″
