Description
Comprehensive Performance
- Carrier Frequency : VHF 200~280MHz
- Frequency Stabilization : LESS THAN ±20ppm
- Dynamic Range : MORE THAN 90dB
- Total Harmonic Distortion : LESS THAN 0.1%
- Frequency Response : 60Hz~13KHz ±3dB
- Audio Output Level : MIX UNBAL 0~700mV (at 20K)
Fixed Receiver
- Power Supply : DC 5V-12V/300mA
- Consume Power : MORE THAN 90dB
- Signal/Noise Ratio : MORE THAN 80dB
- Image & Spurious Rejection : MORE THAN 80dB
- Border Upon Channel Rejection : LESS THAN 5dBuV (SINAD=30dB)
- Receiving Sensitivity : 50uS
Handheld Microphone
- Transmitter Power : 10mW
- Modulation Type : FM
- MAX Deviation : ±50KHz
- Spurious Emission : MORE THAN 40dB (WITH CARRIER)
- Battery Voltage : (2×1.5V) Battery
- Continuum Using : 6 Hours (Compare With GP 1604S 3v
- Noise Control : Perfectness Circuit For Eliminating Noise
