KREZT 234 KZT Crossover Audio 2 Channel Stereo 2 Way / 3 Way / 4 Way

KREZT 234 KZT Crossover Audio 2 Channel Stereo 2 Way / 3 Way / 4 Way

Chat Penjual
Category: Tags: , , , , , , , , , , Brand:
Krezt
Pengiriman Cepat

100% ORIGINAL

Pengiriman Cepat

HARGA Kompetitif

Pengiriman Cepat

GARANSI Resmi

Pengiriman Cepat

AFTERSALES Service

Description

Spesifikasi

  • Bandwidth : 20 Hz to 20 KHz, +0/-0.5 dB
  • Frequency Response : < 3 Hz to > 90 KHz, +0/-3 dB
  • Signal-to-Noise : Ref: +4 dBu,  22 kHz measurement bandwidth
  • Stereo Mode/Mono Mode : 234/234XL Stereo Mode, Mono Mode
  • Low Output : > 94 dB  > 94 dB
  • Low-Mid Output : >94 dB
  • Mid Output : > 93 dB
  • High-Mid Output : >92 dB
  • High Output : > 90 dB > 88 dB
  • Dynamic Range : > 106 dB, unweighted, any output
  • THD+Noise : < 0.004% at +4 dbu,  1 KHz < 0.04% at +20 dBu, 1 KHz
  • Interchannel Crosstalk : < -80 dB, 20 Hz to 20 KHz

Crossover Frequencies

  • 234/234XL : Stereo Mode
  • Low/High : 45 to 960 Hz or 450 Hz to 9.6 KHz  (x10 setting)
  • Low/Mid : 45 to 960 Hz or 450 Hz to 9.6 KHz (x10 setting)
  • Mid/High : 450 Hz to 9.6 KHz
  • 234/234XL : Mono Mode
  • Low/Low-Mid : 45 to 960 Hz or 450 Hz to 9.6 KHz (x10 setting)
  • Low-Mid/High-Mid : 450 Hz to 9.6 KHz
  • High-Mid/High : 450 Hz to 9.6 KHz

Input

  • Connectors : 1/4” TRS (223/234) or XLR (234/234XL)
  • Type : Electronically balanced/unbalanced, RF filtered
  • Impedance : Balanced > 50 kΩ, unbalanced > 25 kΩ
  • Max Input Level : +22 dBu typical, balanced or unbalanced
  • CMRR : >40 dB, typically > 55 dB at 1 KHz

Output (223XL/234XL)

  • Connectors : XLR
  • Type : Electronically-balanced/unbalanced, RF filtered
  • Impedance : Balanced 60Ω, unbalanced 30Ω
  • Max Output Level : > +20 dBu balanced/unbalanced  into 600Ω or greater

Power Supply

  • Operating Voltage : 100 VAC 50/60 Hz,  120 VAC 60 Hz 230 VAC  50/60 Hz
  • Power Consumption : 15 Watts
  • Mains Connection : IEC 320 receptacle
