ibanez AF75G
Hollowbody Electric Guitar with Linden Top, Back, and Sides, Nyatoh Neck, Walnut Fingerboard, and 2 Humbucking Pickups
Description
Features
Nyatoh neck
The Nyatoh neck provides a rich mid-low end.
Gibraltar Performer bridge
The Gibraltar Performer bridge provides rich sustain and tuning stability. The low-positioned saddles promise comfortable playability.
Walnut fretboard
A Walnut fretboard features a well-balanced tonal character from low to high end.
Classic Elite pickups
The Classic Elite pickups offer rich, nuanced tone with fat low-end.
Quik Change III Tailpiece
The Quik Change III tailpiece enables faster and easier string changing.
SPECS
-
neck typeAS ArtcoreNyatohSet-in neck
-
top/back/sideLinden top Linden backLinden sides
-
fretboardBound Walnut fretboardAcrylic block inlay
-
fretMedium frets
-
number of frets22
-
bridgeGibraltar Performer bridge
-
string space10.5mm
-
tailpieceQuik Change III tailpiece
-
neck pickupClassic Elite (H) neck pickupPassive/Ceramic
-
bridge pickupClassic Elite (H) bridge pickupPassive/Ceramic
-
factory tuning1E,2B,3G,4D,5A,6E
-
string gauge.010/.013/.017/.030/.042/.052
-
hardware colorChrome
NECK DIMENSIONS
-
-
Scale :628mm
-
a : Width43mm at NUT
-
b : Width57mm at 22F
-
c : Thickness21mm at 1F
-
d : Thickness24mm at 9F
-
Radius :305mmR
-
BODY DIMENSIONS
-
-
a : Length19 1/4“
-
b : Width15 3/4“
-
c : Max Depth2 5/8“
-
