Golden Age Project PRE-73 MKIII Microphone Preamp

Single-channel Mic/line Preamp with 80dB of Mic Gain, Phantom Power, DI, Switchable Impedance, and LED Output Level Meter

Cek Harga
Share atau Bagikan :

Description

The classic Neve 1073 wrote the book on characterful mic preamplification, so in designing their Pre-73 MKIII mic pre, Golden Age aimed high. Given its mild pricetag, it’s amazing how well they succeeded. The single-channel Pre-73 MKIII is versatile, with 80dB of gain that lets you easily mic subdued sources with passive ribbons. Cranking the main gain stage imbues your tracks with tasty vintage-style coloration. Also onboard: phantom power, a broad gain-range DI, flexible I/O, switchable impedance, and an LED output level meter, all in a robust half-rack chassis. If you want a characterful pre with punch, Sweetwater recommends the Golden Age Pre-73 MKIII.

Features

  • Vintage Style electronics, no intergrated circuits in the signal path
  • Enough gain to handle passive ribbon mics with quiet sound sources
  • GAIN/LINE mode switch, gain is reduced by 30 dB in LINE mode
  • Selectable two position high frequency AIR boost eq, 3 or 6 dB @ 30 kHz
  • Selectable 6 dB/octave two frequency high pass filter
  • Tantalum capacitors in the signal path
  • Switchable impedance in MIC mode
  • Switchable phantom power and absolute phase
  • A high-impedance instrument input
  • A simple but effective 4-step LED output level meter
  • Combo XLR/TRS input jack and separate output XLR and TRS jacks
  • Insert jack for inserting EQs and other units
  • The pcb is prepared for the Carnhill input transformer
  • External power supply to avoid interaction with the audio circuits and transformers
  • A solid build quality that will last many years of normal use

Spesifikasi

I/O 1x XLR/TRS combo input jack
1x XLR output
1x TRS output
Gain 80 dB
Gain Range 20 to 80 dB
Boost Frequency 3 or 6 dB at 30 kHz
HPF Selectable 6 dB/octave high pass filter at around 40 (HP1) and 170 Hz (HP2)
Input Impedance Mic: Switchable 1200 or 300 ohms in mic mode
Line: 10 kOhms
Output Impedance Selectable 600 ohm output termination
LED 4-step meter
Dimensions Not specified by the manufacturer
Weight Not specified by the manufacturer
Packaging Info
Package Weight 7.05 lb
Box Dimensions (LxWxH) 14.2 x 12.8 x 3.7″
