d&b Audiotechnik Yi7P Speaker Point Source Pasif 2x8 Inch 2 Way 8 Ohm 1600 Watt (Waterproof)
d&b Audiotechnik Yi7P Speaker Point Source Pasif 2x8 Inch 2 Way 8 Ohm 1600 Watt (Waterproof) - Image 2
d&b Audiotechnik Yi7P Speaker Point Source Pasif 2x8 Inch 2 Way 8 Ohm 1600 Watt (Waterproof) - Image 3

d&b Audiotechnik Yi7P Speaker Point Source Pasif 2×8 Inch 2 Way 8 Ohm 1600 Watt (Waterproof)

Installation specific high performance 2-way passive point source loudspeaker

  • Components 2 x 8″/1.4″
  • Dispersion 75° x 40°
  • SPLmax 137 dB
  • Weight 18 kg / 40 lb

Chat Penjual
Category: Brand:
D&b Audiotechnik
Pengiriman Cepat

100% ORIGINAL

Pengiriman Cepat

HARGA Kompetitif

Pengiriman Cepat

GARANSI Resmi

Pengiriman Cepat

AFTERSALES Service

Description

The compact, 2-way passive Yi7P loudspeaker features two 8” drivers in a dipole arrangement with a 1.4” compression driver mounted onto a rotatable CD horn. The Yi7P is the installation version of the Y7P loudspeaker and differs only in cabinet construction, finish and mounting hardware. Sophisticated horn geometry combined with the advanced bass-reflex port design delivers full bandwidth capabilities with an extended LF output. These point source, high performance cabinets offer 75° horizontal directivity controlled down to 500 Hz, matched with a vertical dispersion of 40°. The horn can be rotated by 90° to enable horizontal orientation. The Yi7P provides a broad variety of deployment possibilities, especially when used as a stand-alone full range system, or combined with other elements from the Y-Series, either ground stacked or flown. The loudspeaker cabinet is constructed from marine plywood and has an impact resistant paint finish while Weather Resistant (WR) and Special Color (SC) versions are available. The Weather Resistant option provides an IP55 rating, and enables operation of loudspeakers in changing ambient conditions.

System data
  • Frequency response (-5 dB standard) 59 Hz – 18 kHz
  • Frequency response (-5 dB CUT mode) 118 Hz – 18 kHz
  • Max. sound pressure1
    • with 10D 132 dB
    • with D20/30D 135 dB
    • with D40/D80/40D 137 dB
  • Cabinets per amplifier channel 2
Loudspeaker data
  • Configuration Installation specific high performance 2-way passive point source loudspeaker
  • Nominal impedance 8 Ω
  • Power handling capacity (RMS/peak 10 ms) 400/1600 W
  • Components
    • 2 x 8″ driver with neodymium magnet
    • 1.4″ exit compression driver
  • passive crossover network
  • Connections
    • 2 x NL4
    • screw terminal block
Dimensions / weight
  • Dimensions (H x W x D)
    • 580 x 257 x 341 mm
    • 22.8 x 10 x 13.4″
  • Weight
    • 18 kg
    • 40 lb

1 1 m, free field, SPL max peak test signal: pink noise with crest factor 4, one speaker driven
