DAS LARA-100 Speaker Line Array Aktif 2×12 Inch 4 Way 6000 Watt
Active, 4-way, 2×12” + 2 x 8” + 2 x 3” compression driver, 2 x 8” cardioid system with ALMA network management
100% ORIGINAL
HARGA Kompetitif
GARANSI Resmi
AFTERSALES Service
Description
LARA® is a 4-way symmetrical, cardioid, self-amplified line array system with 6000Wrms power. LARA® has a linear performance of 146 dB SPL MAX and a wide dynamic range making it an ideal system for large events. Thanks to the cardioid design, we achieve a rear attenuation of -15 dB in the range of 63 Hz – 200 Hz.
LARA® incorporates 2 x 12″ woofers with a 4″ voice coil plus another 2 x 8″ in cardioid configuration; for the midrange, it uses another 2 x 8″ speakers with 2.5″ voice coils. The high-frequency section is made up of two DAS M-78N compression drivers, with 3″ voice coils and a 100º horizontal dispersion waveguide. All the elements have been designed and purpose-built to maximize the system’s efficiency.
The LARA® class D amplifier integrates a switching power supply with power factor correction (PFC), ensuring maximum performance and efficiency regardless of the mains voltage. Each amplifier provides 6000Wrms divided into eight channels, 6 of them in bridge mode to feed the 2 x 12″ and the two compression drivers. The remaining two channels feed the front 2 x 8″ and rear 2 x 8″ transducers.
The 3-point rigging system works for both LARA® and LARA® SUB, allowing us to hang arrays of up to 24 LARA units and 16 LARA® SUB units. The FSS TM (Fast Set Splay) angulation system allows angles to be adjusted in steps of 1º, from 0º to 7º from the stacked position, significantly reducing assembly time.
| Performance | |
| Frequency Range (-10 dB) | 50 Hz – 18 kHz |
| Horizontal Coverage (-6 dB) | 100º |
| Vertical Coverage | Splay Dependent |
| Maximum Linear SPL1 | 146 dB |
| Maximum SPL2 | 150 dB |
| 1. Measured Maximum Linear SPL at 1m according to AES75 standard using 18dB crest factor M-Noise. 2. Measured Maximum SPL at 1m using burst noise. |
|
| Electronics and Connectors | |
| Nominal Amplifier Power (continuous) | 6000 W |
| Input Type | Balanced Analog |
| Input Impeadance | 20 kohms |
| Input Sensitivity | 6.2 V (+18 dBu) |
| Audio Signal Input Connector | 1 x Female XLR |
| Audio Signal Loop Thru Connector | 1 x Male XLR |
| Audio/Data Input Connector | etherCON |
| Control | ALMA |
| Audio + Data Loop Thru Connector | etherCON |
| AC Output Connector | powerCON TRUE1 |
| Current Draw 230 V / 115 V | 7.5 A/15 A |
| Sampling Rate | 96kHz |
| Enclosure | |
| Enclosure Construction | Birch Plywood |
| Enclosure Geometry | Trapezoidal 7º |
| Rigging | Captive Rigging System |
| Finish | ISO-flex Paint |
| Color | Black |
| IP Rating | IP43 |
| Dimensions ( H x W x D ) | 355 x 1.170 x 645 mm 14,0 x 46,0 x 25,4 in |
| Net Weight | 86,0 kg ( 189,6 lb ) |
| Components | |
| LF Driver | 12GXNC |
| MF Driver | 8MXN |
| LF Cardioid Driver | 8GXN |
| HF Driver | M-78N |
