Canare 4S8 Kabel Speaker Star Quad 4-Conductor 16 AWG 100m
Star Quad Speaker cable Copper 4×1.3mm² Ø 8mm
Description
Speaker cable must accommodate relatively high signal levels, typically tens to hundreds of watts of RMS power. Electromagnetic interference (EMI) can radiate from these speaker lines directly into adjacent low voltage cables (i.e. microphone, video lines, etc.). Canare solves this problem by using a 4-conductor “Star Quad” configuration in all of our 4S Series speaker cables. Because every conductor is located the same distance from the center, the opposing magnetic fields are cancelled out. Attenuation of magnetic field radiation is superior when compared to a standard 2-conductor speaker wire.
Our most popular 4 x 16 AWG flexible speaker cable. Perfect choice for all broad spectrum speaker systems and general purpose power amp setups. Good on Bi-Amped applications.
Features:
- Ideal for PA Systems, Hi-Fi Speakers and DC Power Lines
- Super Flexibility, even in Sub-Zero Weather
- Star Quad Design Reduces EMI Noise
- Low Capacitance and Resistance
Specifications:
- Colour: Black
- Conductor Size: 1.27mm2
- Outside Diameter: 2.49 mm
- Roll Length: 100 metre
- Weight: 9.5Kg per 100 metre
Spesifikasi
| TECHNICAL CHARACTERISTICS | |
|---|---|
| number drivers | x4 |
| conductive material | annealed copper |
| sectional area | 4x 1.31 mm² (16AWG) |
| total diameter | Ø 8 mm |
| Isolation | polyethylene |
| Body | PVC (flexible) |
| sheath color | Grey or black (depending on arrivals) |
| Sold | the meter |
| MECHANICAL CHARACTERISTICS | |
|---|---|
| Model | 4S8 |
| Weight / meter | 0.19kg |
| overall diameter | 8.3 mm |
| PCV sheath thickness | 1.1 mm |
| Brittle pint | -49°C |
| Number of conductors | x4 (Red, clear Red, White, clear White) |
| Insulating | PE 0.5 mm |
| Conductor – AWG | AC # 16 # 13 (combined biwiring) |
| Quad Cable pitch | 70 mm |
| ELECTRICAL PERFORMANCE | |
|---|---|
| Model | 4S8 |
| Cond. D.C.R. | 1.5 ohm / 100 m |
| Nominal capacitance between red and white wires | 145 pF / m |
