Bose ShowMatch SMS118 Subwoofer Pasif 18 Inch 4 Ohm 3000 Watt (Waterproof) - Image 2
Bose ShowMatch SMS118 Subwoofer Pasif 18 Inch 4 Ohm 3000 Watt (Waterproof) - Image 3

Bose ShowMatch SMS118 Subwoofer Pasif 18 Inch 4 Ohm 3000 Watt (Waterproof)

Chat Penjual
Category: Tags: , , , , , , , , , , , , , , , , Brand:
Bose
Pengiriman Cepat

100% ORIGINAL

Pengiriman Cepat

HARGA Kompetitif

Pengiriman Cepat

GARANSI Resmi

Pengiriman Cepat

AFTERSALES Service

Description

Bose Professional ShowMatch SMS118 subwoofers are designed primarily to integrate with DeltaQ array loudspeakers and extend low-frequency response down to 29 Hz. The SMS118 enclosure width and integrated rigging allows fast integration in arrays with ShowMatch full-range modules using optional array frames and accessories. The portable-rated Baltic birch enclosure may also be used for ground-stack applications and includes an integrated mounting-pole adapter for use with other mid/high loudspeakers.

Fitur

  • DeltaQ™ technology – defines the next-generation in loudspeaker array design with selectable coverage patterns that more precisely direct sound to audience areas for improved sound quality and vocal clarity with fewer boxes versus line arrays.
  • ShowMatch™ companion 1x 18” subwoofer – for low-frequency extension down to 29 Hz with mixed mid/high and subwoofer ShowMatch arrays
  • Bose LF18 neodymium 18-inch, high-excursion, 4.5-inch voice coil, transducer provides maximum performance (same transducer as in Bose RMS218)
  • Integrated 4-point “quick pin” rigging – allows arrays of up to 18 subwoofers with 10:1 design factor
  • Front-grill mounted NL4 input, plus rear NL4 inputs – allow easy setup for “reversed-box” cardioid arrays
  • Integrated pole-cup adapter – allows use with other mid/high loudspeakers and accessory mounting poles

Spesifikasi

SINGLE MODULE PERFORMANCE
Frequency Response (-3 dB) (1) 32 – 250 Hz
Frequency Range (-10 dB)  29 – 300 Hz
Recommended High-Pass Protection Filter  30 Hz with minimum 12-dB / octave filter
Nominal Coverage Pattern  omni with cardioid array configuations
Recommended Crossover  60-100 Hz (requires active crossover in DSP)
  Bose extended-lifecycle test (4) AES transducer test (5)
  Array (free field) Ground Stack (half space)  Array (free field)  Ground Stack (half space)
Power Handling, long-term continuous  750 W  750 W  1250 W  1250 W
Power Handling, peak  3000 W  3000 W  5000 W  5000 W
Sensitivity (SPL/ 1W @ 1 m) (2)  92 dB  98 dB  92 dB  98 dB
Calculated Maximum SPL @ 1 m (3)  121 dB  127 dB  123 dB  129 dB
Calculated Maximum SPL @ 1 m, peak  127 dB  133 dB  129 dB  135 dB
TRANSDUCERS
Low Frequency  1 x Bose LF18 neodymium 18-inch, high-excursion woofer (4.5-inch voice coil)
Nominal Impedance  4 ohms
PHYSICAL
Enclosure  Material Baltic birch plywood
Finish  Two-part spray polyurethane coating, black
Grill  16-gauge (1.5 mm) perforated steel, powder-coated finish, black
Environmental  IPx4
Connectors  2 x Neutrik® NL4 on rear, 1x NL4 front-grill mounted; all wired parallel
Suspension / Mounting  4-point “quick pin” rigging; 4x M10 top and 4x M10 bottom inserts; M20 pole cup
Dimensions (H x W x D)  21.2” x30.1” x30.5” (540 x 765 x 775 mm) / W: XX side guards removed
Net Weight  136.5 lbs (61.9 kg)
Shipping Weight  145 lbs (65.8 kg)
Accessories rigging frames, ground stack bracket, short quick pins
