Bose DesignMax DM5SE Speaker Wall Mount 5.25″ 240 Watt
Description
The Bose DesignMax DM5SE combines top-flight sound quality with appealing aesthetics. This 50-watt speaker contains a 3.25-inch woofer and 0.75-inch tweeter that reproduce every nuance of the 65Hz to 20kHz frequency range — no DSP or EQ required. Beyond that, Bose’s acclaimed Dispersion Alignment system ensures a consistent listening experience for everyone in the room. Worried about installation? Don’t be — the DM5SE’s QuickHold U-bracket makes it fast and easy. You can even install it outdoors, thanks to its weather-resistant, IP55-rated aluminum grille. The DesignMax DM5SE works with a wide range of amplifiers, while combined 70-volt/100-volt and low-impedance operation supply super-versatile operation.
Bose DesignMax DM5SE Loudspeaker Features:
- 50-watt, 8-ohm 2-way speaker
- Combines top-flight sound quality with appealing aesthetics
- 5.25-inch woofer and 1-inch tweeter reproduce every nuance from 65Hz to 20kHz without DSP or EQ
- Dispersion Alignment system ensures a consistent listening experience for everyone in the room
- QuickHold U-bracket ensures easy installation
- Weather-resistant, IP55-rated aluminum grille
- Works with a wide range of amplifiers
- Combined 70-volt/100-volt and low-impedance operation for added versatility
Applications
- Performing arts venues
- Places of worship
- Conference centers
- Retail stores
- Restaurants and bars
- Hospitality venues
Spesifikasi
Frequency Response (+/-3 dB)
73 – 17,000 Hz
Nominal coverage (H x V)
135° conical
Power Handling, peak
240 W
Maximum SPL @ 1m
107 dB
Frequency Range (-10 dB)
65 – 20,000 Hz
Power Handling, long-term continuous
60 W
Sensitivity (SPL/1W @ 1 m)
89 dB
Nominal Impedance
8 Ω (transformer bypass)
