BOSCH LC2-PC60G6-10 Subwoofer Ceiling Pasif 10 Inch 8 Ohm 60 Watt (High Impedance)
Subwoofer ceiling loudspeaker 60 W, 10-inch highexcursion driver, low pass network with overload protection, 3-way ceramic screw terminal block, supplied with tile bridge/C-ring, white RAL 9010 (set of 2 pieces).
100% ORIGINAL
HARGA Kompetitif
GARANSI Resmi
AFTERSALES Service
Description
The LC2‑PC60G6‑10 is an 10‑inch Premium‑sound Subwoofer Ceiling Loudspeaker which is designed to augment the low frequency response of any LC2 Premium‑sound full range ceiling loudspeaker. It consists of a baffle assembly, grille, back‑can enclosure, 10‑inch coax high‑excursion LF loudspeaker and internal output‑power matching transformer. The rear enclosure and loudspeaker provides an optimum internal volume for extended low frequency performance. The loudspeaker utilizes a second order crossover network to provide the correct band‑pass frequency response for use with any LC2 Premium‑sound full range ceiling loudspeaker.
Fitur
- 10‑inch high-excursion loudspeaker for extended LF
- Low pass network with overload protection
- Front baffle wattage tap adjustment
- Includes tile bridge and mounting ring for easy installation
- BS 5839‑8 and EN 60849 compliant
Spesifikasi
| Electrical Specifications | |
|---|---|
| Maximum Power | 100 W |
| Rated Power | 60 / 30 / 15 / (7.5 W only, 70 V) |
| Sound Pressure Level (at 60 W / 1 W, 70 Hz, 1 m) | 112 / 94 dB (SPL) |
| Effective Frequency Range (-10 dB) | 45 Hz to 150 Hz |
| Coverage (Conical) | 180° |
| Rated Voltage | 70 V or 100 V |
| Rated Impedance | 83 or 167 or 8 ohm |
| LF Transducer | 254 mm (10 in.) Polypropylene cone |
| Connector | 3-pole ceramic screw terminal block |
| Mechanical Specifications | |
| Diameter | 350 mm (13.8 in) |
| Maximum Depth | 303 mm (11.9 in) |
| Ceiling Thickness | 4 to 25 mm (0.16 to 1.00 in.) |
| Mounting Cut-out | 322 + 5 mm (10.75 + 0.20 in.) |
| Material – Baffle | ABS (UL94V0) |
| Material – Back-can | Zinc-plated steel |
| Material – Grille | Powder coated steel |
| Weight | 7 kg (15.5 lb) |
| Color | White (RAL 9010) |
| Environmental Specifications | |
| Operating Temperature | -25 ºC to +55 ºC (-13 ºF to +131 ºF) |
| Storage Temperature | -40 ºC to +70 ºC (-40 ºF to +158 ºF) |
| Relative Humidity | <95% |
