Audiocenter AVANDA 210A Speaker Line Array Aktif 2×10 Inch 2 Way 3200 Watt
Dual 10” two-way active DSP controlled line array speaker
100% ORIGINAL
HARGA Kompetitif
GARANSI Resmi
AFTERSALES Service
Description
AVANDA 210A is a dual 10” two-way active DSP controlled line array speaker. Designed for medium to large-scale sound reinforcement applications and mid-to-high-end fixed installations, it provides a high quality and poweful sound, meeting the requirements of any sound reinforcement application, indoors or outdoors.
The AVANDA 210A achieves a narrow vertical coverage in the high frequency range through the innovative ARROWHEAD™ waveguide technology, providing a clearer sound performance.The 90° horn provides a precise horizontal coverage and ensure that the system delivers an even and smooth sound.
CNC machined birch plywood cabinet, coated with polyurea, is waterproof, wear and high temperature resistant.
Key Features
- Perfect integration of Braincore™ technology achieves supreme performance of the speaker system
- ARROWHEAD™ waveguide technology
- 3 presets
- High end DSP, with 96KHz signal sampling frequency, with FIR filter
- Class D amplifier
- Automatically enter sleep mode after 45 minutes without signal input
- Advanced temperature control system
- Customized driver
- Optimized, compact cabinet design
- Durable polyurea coating
- CNC machined birch plywood cabinet, coated with polyurea, is waterproof, wear and high temperature resistant
Specifications
|
Type |
Dual 10” two-way active DSP controlled line array speaker |
|
Frequency Response(-6dB) |
55Hz-20kHz |
|
Maximum Calculated SPL/1M (Continuous/Peak) |
132dB/138dB |
|
LF |
Customized 2×10”driver, 2.5” voice coil |
|
HF |
Customized Neodymium driver,2×3”voice coil, 1.4”exit voice coil |
|
Horizontal Coverage |
90° |
|
Vertical Coverage |
Splay angle dependent |
|
AMPLIFIER |
|
|
Amplifier Circuitry |
Class D |
|
Power(RMS standards) |
1600W |
|
Frequency Response(1W 8Ω 2ch) |
20Hz-20kHz(±0.5dB) |
|
Intermodulation Distortion |
＜0.05% |
|
Total Harmonic Distortion |
＜0.05% |
|
Protection |
DC protection, short circuit protection, overheat protection, input overload protection, output overload protection, soft startup protection, overvoltage protection, undervoltage protection |
|
Cooling System |
Cooling with fans, air convection |
|
DSP |
|
|
Processor |
96kHz signal sampling frequency, FIR filtering |
|
Presets |
4 Units,8 Units,12 Units |
|
Output/Input |
|
|
Signal Input |
1× female XLR |
|
Signal Output |
1× male XLR |
|
Power Input |
Power connector |
|
Power Output |
Power connector |
|
Working Voltage |
100V-130V~ or 220V-240V~(±10%,50/60Hz) |
|
Power consumption(1/8 output power) |
142W |
|
Cabinet |
|
|
Angle Adjustment |
0°, 1°, 2°, 4°, 6°, 8°, 10° |
|
Cabinet Material |
Russian birch plywood |
|
Coating |
Durable Polyurea Coating |
|
Cabinet Color |
Black is the default color. Contact Audiocenter for customization |
|
Dimension(W×H×D) |
830×293×420mm |
|
Net Weight |
39.0Kg |
