Allen & Heath ZED-18 18-Channel Analog Mixer With USB
18-channel Multipurpose Mixer with 10 Mic/Line Channels, 4 Stereo Channels, USB, and SONAR LE Recording Software
Description
ZED-18 has an incredibly advanced feature-set for a mixer at this level – it gives musicians, venues and hire companies access to 10 full mono channels and 4 stereo channels in a compact, rack mountable format. Configurable USB audio in/out makes it easy to capture stereo recordings.
USB Audio Flexibility
The ZED-18 is super flexible and super easy thanks to the USB integration. This makes it ideal for getting audio to and from your computer, making it perfect for live sound and music production. Simply plug in the ZED mixer to your PC through USB and select the USB routing on the mixer and the device on your computer, and you’re ready to go. The ZED mixer retains the quality of audio through to your PC or Mac.
Inputs
The ZED-18 features 10 full mono channels, 4 stereo channels and 4 auxiliary channels with an EQ on each channel making the ZED-18 incredibly versatile and practical. Whether you are recording in the studio or controlling sound at a live show, the ZED mixer has got your covered with the inputs you need.
DuoPre
The Allen & Heath ZED-18 comes with the highly successful and proven DuoPre preamps that have carefully controlled gain over the dual stages. The DuoPre’s have a 69dB gain range that gives superb control over the signal level thanks to its even distribution around the gain control. The ZED-18 has 18 DuoPre preamps. Most of the gain comes from the first stage, so that any unwanted noise is kept at minimum levels. The line level signals are plugged into the second stage of the preamp by using the line input jack. The advantage of this is that there is less noise when using the lineinput and also matching to a higher input impedance.
MusiQ
ZED-18 features a 3-band swept mid frequency EQ that utilises MusiQ, with optimised slope for individual EQ of instruments.
Sonar X1 LE
The ZED-18 includes Cakewalks’ SONAR X1 LE to enable you to create your own music instantly. You will be able to create tracks, arrange songs and record straight from your ZED mixer, then you are able to play back to the ZED-18 via the USB port. The ZED and SONAR can be used together in different ways, for example you can use them for recording tracks individualy to build up a song, simple recording or by using the USB port and software as an effects loop.
SONAR X1 LE Features
- Powered by SONAR X1
- 32 audio tracks
- 64 MIDI tracks
- 8 simultaneous inputs and outputs
- 24-bit/96 kHz audio quality
- 24 simultaneous effects
- 8 simultaneous virtual instruments
Features
- 10 mono channels
- Neutrik mic XLR
- Neutrik 1/4 inch jacks
- Channel insert
- Super wide gain ‘DuoPre’ mic line input
- 3 band EQ with MusiQ
- 4 auxes
- Illuminated mute
- Sound image pan
- Illuminated PFL & peak warning indicator
- ALPS 100mm faders
- 4 stereo channels with 2-band EQ
- Stereo returns & playback
- All inputs with level control
- 12 bar meters
- Mono/stereo function on auxes 1&2
- Monitor output section
- Alt stereo output source
- Configurable USB stereo audio in/out
- Global +48V phantom power
- Cakewalk SONAR LE bundled with mixer
- Rackmountable
Spesifikasi
| Total # Of Inputs | 18 |
| Mic/Line Inputs | 3-pin XLR Balanced Microphone x10 1/4″ Phone Balanced Line x10 |
| Stereo Line Inputs | ST1 – ST4 1/4″ Phone L/R Stereo |
| In-Line Inputs/Returns | No |
| AUX Sends | 1/4″ TRS Phone x4 |
| AUX Returns | 1/4″ TRS Phone x4 |
| Inserts | 1/4 TRS Phone x12 (Mono chs and Main Stereo Out) |
| BUS (Group) Outputs | No |
| 2 Trk Master I/O | Main Output: Balanced 3-pin XLR |
| ALT I/O | USB Connector 1/4″ Phone Mono Out |
| Monitor Outputs | RCA Stereo Phono – ALT Out RCA Stereo Phono – REC Out |
| EQ Section | 3-Band with Mid Sweep On all Mono Channels 2-Band On Stereo Channels |
| Solo/Mute | Mute and PFL Solo |
| Channel Level Control | 100mm Fader |
| Trim/Gain Control | Rotary Control |
| Phantom Power | +48V Switched Globally |
| Metering | 12 Segment Peak LEDs |
| Frequency Response | Mic in to Mix L/R Out, 30dB gain: +0.5/-1dB 20Hz to 20kHz Line in to Mix L/R out 0dB gain: +0.5/-1dB 10Hz to 30kHz Stereo in to Mix L/R out: +0.5/-1dB 10Hz to 30kHz |
| Headroom | Analogue Headroom from nominal (0Vu): 21dB USB in & out headroom from nominal (0Vu): 14dB |
| Signal-to-Noise Ratio | Mic Pre EIN @ max gain 150R input Z 22-22kHz: -127dBu Mix L/R out, L/R faders = 0, 22-22kHz: -86dBu |
| Total Harmonic Distortion (THD) | Mic in to Mix L/R Out, 0dB gain 1kHz +10dBu out: 0. 004% Mic in to Mix L/R Out, 30dB gain 1kHz: 0. 014% Line in to Mix L/R out 0dB gain 0dBu 1kHz: 0. 005% Stereo in to Mix L/R out 0dB gain +10dBu 1kHz: 0. 003% |
| USB | USB Audio In/Out: USB 1.1 compliant 16-bit Sample Rate: 32, 44.1, or 48kHz |
| Dimensions (WxHxD) | 18.3 x 3.85 x 18.3″ (464 x 98 x 465mm) |
| Weight | 18.7 lb (8.5 kg) |
| Packaging Info | |
|---|---|
| Package Weight | 24.0 lb |
| Box Dimensions (LxWxH) | 24.2 x 23.5 x 10.2″ |
