Allen & Heath DX168 16×8 Digital Snake Stage Box
16-in/8-out Portable DX Expander for dLive Systems
Description
The DX168 is a rugged, portable expander for adding remote I/O to a dLive S Class or dLive C Class system.Each DX168 comes loaded with 16 great-sounding mic preamps that can be placed conveniently on the stage floor. The DX168 is a breeze to set up, thanks to its Plug and Play design, and is compatible with Cat 5e cables of up to 100m. This portable DX Expander weighs a measly 10-1/2 pounds and features a carry handle for easy transport. The DX168 works with both S Class and C Class dLive, along with SQ systems.
Offers impressive levels of expandability
The DX168, when used in conjunction with a Surface and MixRack, combines to form a powerful and expandable system. The Surface provides you with direct hands-on control over your mix. The MixRack is the brain of the system, containing the XCVI core, and is supported by a whole host of surfaces, apps, software, TCP/IP control, and IP remotes, all of which provide different means of controlling the mixer. A 128-channel I/O port supports Dante, Waves SG, ACE, and MADI, along with full compatibility with ME personal mixing systems. At Sweetwater, we’ve found these systems to be flexible enough to tackle any mixing challenge that we throw at them.
Allen & Heath DX168 Features:
- 16 Mic Preamps on XLR with Phantom Power status LEDs
- 8 XLR Line Outs
- Compatible with dLive S Class and dLive C Class hardware
- Up to 6 DX168 units can be added to a dLive system for 96 inputs / 48 outputs
- Cascade mode allows daisy-chaining of 2 DX168 Expanders for additional I/O (requires firmware 1.60 or higher)
- Redundant DX connection to dLive S Class hardware
- Optional 19-inch rack mount kit available
- Plug and Play – no IP addressing required
- Compatible with CAT5e (or higher) cables of up to 100m
- Rubber bumpers
- Carry handle
Spesifikasi
- Type:DX I/O Expander
- Compatibility:dLive S/C Class Systems
- Channels:16 x 8
- Inputs – Mic Preamps:16 x XLR
- Phantom Power:16 channels
- Outputs – Main:8 x XLR (line outs)
- Data I/O:2 x EtherCon (Cat5e DX ports)
- Rackmountable:Yes (kit sold separately)
- Power Source:Standard IEC AC cable
- Manufacturer Part Number:AH-DLIVE-DX168
